High-Efficiency Baking Lamps for Energy-Saving Paint Drying Solutions

Product Description

Shandong Dongda Profile Shandong Dongda Electromechanical Technology Co., Ltd. specializes in R&D, design, manufacture, installation of automotive spray booths, furniture spray booths, curtain spray booths, purifiers and other auto maintenance and environmental protection equipment. It is a specialized and modern machinery manufacturing company. The company was founded in 1999 and was transformed from Zouping County Yuanda Paint Equipment Factory. It is located in Zouping, one of the top 100 counties in CHINA. 33 kilometers away from Zibo CITY in the east, 68 kilometers away from JINAN CITY in the west, JINAN-QINGDAO Expressway in the south, and the Yellow River in the north. The geographical position is superior and the transportation is convenient. Since the establishment of the company, it has been dedicated to doing things, all kinds of documents are complete, and the environmental assessment procedures are complete.Custom design of spray booth is the biggest advantage of DONGDA.

Models	High temperature baking lamp
Power supply	220V/50HZ/1PH
Current	4.5KW
Size LxWxH	630*150*50
Power	1KW
Temperature	40~100ºC
Heating area	3m
Baking distance	>500mm
Preheat time	5s
Net weight	0.85kg

Models	White tube carbon fiber baking lamp
Power supply	220V/50HZ/1PH
Current	13.5A
Size LxWxH	680*310*50
Power	3KW
Temperature	40~120ºC
Heating area	10m
Baking distance	>500mm
Preheat time	5s
Net weight	2.9kg

Models	High temperature baking lamp
Power supply	220V/50HZ/1PH
Current	13.5A
Size LxWxH	680*310*50
Power	3KW
Temperature	40~120ºC
Heating area	10m
Baking distance	>500mm
Preheat time	5s
Net weight	2.9kg

Models	High temperature baking lamp
Power supply	220V/50HZ/1PH
Current	13.5A
Size LxWxH	560*580*80
Power	3KW
Temperature	40~120ºC
Heating area	10m
Baking distance	>500mm
Preheat time	5s
Net weight	8.0kg

Models	High temperature baking lamp
Power supply	220V/50HZ/1PH
Current	13.5A
Size LxWxH	570*370*70
Power	3KW
Temperature	40~120ºC
Heating area	8m
Baking distance	>500mm
Preheat time	5s
Net weight	1.8kg

Models	High temperature baking lamp
Power supply	220V/50HZ/1PH
Current	13.5A
Size LxWxH	580*400*80mm
Power	3KW
Temperature	40~120ºC
Heating area	10m
Baking distance	>500mm
Preheat time	5s
Net weight	5.6kg

Models	High temperature baking lamp
Power supply	220V/50HZ/1PH
Current	13.5A
Size LxWxH	580*400*80
Power	3KW
Temperature	40~120ºC
Heating area	10m
Baking distance	>500mm
Preheat time	5s
Net weight	5.6kg

Models	High temperature baking lamp
Power supply	220V/50HZ/1PH
Current	13.5A
Size LxWxH	640*460*70mm
Power	3X1000W
Temperature	40~120ºC
Heating area	8m
Baking distance	>300mm
Preheat time	30s
Net weight	4kg

Models	High temperature baking lamp
Power supply	220V/50HZ/1PH
Current	13.5A
Size LxWxH	760*560*60mm
Power	3X1000W
Temperature	40~180ºC
Heating area	10m
Baking distance	>500mm
Preheat time	30s
Net weight	8.7kg

Models	Ceramic plate radiator
Power supply	220V/50HZ/1PH
Current	9A
Size LxWxH	650*460*90mm
Power	2KW
Temperature	60~180ºC
Heating area	6.6m
Baking distance	>500mm
Preheat time	30s
Net weight	7kg

Models	quantum radiator
Power supply	220V/50HZ/1PH
Current	9A
Size LxWxH	650*460*90mm
Power	2KW
Temperature	40~120ºC
Heating area	6.6m
Baking distance	>500mm
Preheat time	30s
Net weight	8.6kg

Models	Nano-coated radiator
Power supply	220V/50HZ/1PH
Current	11A
Size LxWxH	930*520*55
Power	2.4KW
Temperature	40~120ºC
Heating area	8m
Baking distance	>300mm
Preheat time	30s
Net weight	16kg

Models	Nano-coated radiator
Power supply	220V/50HZ/1PH
Current	11A
Size LxWxH	800*58*50mm
Power	2.4KW
Temperature	40~120ºC
Heating area	8m
Baking distance	>300mm
Preheat time	30s
Net weight	12.5kg

Models	Nano-coated radiator
Power supply	220V/50HZ/1PH
Current	11A
Size LxWxH	1000*550*35mm
Power	2.4KW
Temperature	40~120ºC
Heating area	8m
Baking distance	>300mm
Preheat time	30s
Net weight	16.2kg

Models	Nano-coated radiator
Power supply	220V/50HZ/1PH
Current	5.5A
Size LxWxH	1000*270*55
Power	1.2KW
Temperature	40~120ºC
Heating area	4.5m
Baking distance	>300mm
Preheat time	30s
Net weight	8.6kg

Models	3kwquantum radiator
Power supply	220V/50HZ/1PH
Current	13.5A
Size LxWxH	650*460*90
Power	3KW
Temperature	40~120ºC
Heating area	10m
Baking distance	>500mm
Preheat time	30s
Net weight	10.5kg

Models	hand-held roasting lamp
Power supply	220V/50HZ/1PH
Current	3.6A
Size LxWxH	300*175*100
Power	0.8KW
Temperature	60~100ºC
Heating area	1m
Baking distance	>500mm
Preheat time	5s
Net weight	1.95kg

Models	High temperature baking lamp
Power supply	220V/50HZ/1PH
Current	4.5A
Size LxWxH	590*170*95
Power	1KW
Temperature	40~120ºC
Heating area	2m
Baking distance	>500mm
Preheat time	5s
Net weight	3.5kg

Finished product display Frequently Asked Questions (FAQ):Here's the text with the key points in bold:
1. What is the primary function of baking lamps in a spray booth?The primary function of baking lamps in a spray booth is to accelerate the drying and curing process of paint. By emitting infrared rays or other forms of heat, they can quickly raise the temperature inside the spray booth, allowing the coating to reach the desired hardness and gloss faster.
2. Do baking lamps require specific voltage and power?Yes. Baking lamps typically require specific voltage (such as 220V or 380V) and power (usually between 1KW to 5KW) to operate effectively and achieve the desired heating effect. It's essential to ensure that the electrical requirements match the power configuration of your spray booth before purchasing.
3. How do I know if a baking lamp needs to be replaced?If the baking lamp shows signs of slower heating, uneven heating, or is unable to reach the set temperature, it may indicate that the lamp is aging or damaged. Regularly checking the surface condition of the lamp for cracks, discoloration, or electrode aging can also help determine if a replacement is needed.
4. What is the typical lifespan of a baking lamp?The lifespan of baking lamps usually ranges between 5,000 to 8,000 hours, depending on usage frequency, environmental conditions, and the quality of the lamp. High-quality lamps, when properly maintained and used correctly, can last longer.
5. Can the temperature of the baking lamp be adjusted?Most baking lamps in spray booths are equipped with a temperature control system that allows the temperature to be adjusted according to different coating requirements. These control systems typically include thermostats and timers, allowing users to precisely set the operating temperature and time of the lamp.
6. What safety precautions should be taken when using baking lamps?When using baking lamps, ensure there are no flammable materials nearby and maintain good ventilation. Avoid direct contact with the lamp surface during operation to prevent burns. Additionally, regularly check electrical connections for looseness or aging to prevent electrical fires.
7. What are the advantages of baking lamps compared to traditional heating systems?Baking lamps can quickly and evenly heat specific areas, significantly reducing drying and curing time. This not only improves production efficiency but also reduces energy consumption. Compared to traditional heating systems, baking lamps offer more concentrated heat, providing a higher surface temperature for better coating quality.
8. Can baking lamps be used with different types of coatings?Yes, baking lamps in spray booths are suitable for various types of coatings, including water-based paints, oil-based paints, and clear coats. Different types of coatings may require different temperatures and baking times, so adjustments should be made according to the specific coating requirements.
9. What should I do if the baking lamp suddenly stops working?If the baking lamp suddenly stops working, first check if the power supply is normal, and if the wires and plugs are damaged or loose. If the electrical components are fine, it may be an issue with the lamp itself, and it is advisable to contact a professional for inspection and repair.
10. Are baking lamps easy to install and replace?Most baking lamps are designed to be modular, making them easy to install and replace. Usually, simple tools and basic electrical knowledge are sufficient to complete the replacement. However, if you are not familiar with electrical equipment, it is recommended to have a professional handle the installation and replacement to ensure safety.
These FAQs cover common issues related to baking lamps in spray booths, helping users better understand and use the equipment. If there are other specific questions, feel free to ask!
