40*SMD5050 RGB LED Video Pixel Strip Pixel Bar Light DMX512 & Cat-5 Network Art-Net Dual Protocol
US$45.00
1-19 Pieces
US$42.00
20-49 Pieces
US$38.00
50+ Pieces
Basic Info.
Model NO.
LED 40-SMD5050
IP Rating
IP33
Diffuser
Tempered Glass
Beam Angle
25°/30°
Lifespan
10000 hours
Warranty
2 Years
Certification
CE
Electric Current Type
AC
Input Voltage
AC90-240V
LED Current
1.6A
Strobe
30 Flashed Per Second (Any Color)
Maximum Ambient Temperature
40ºC
Angle
120°
Brightness
22 Lux/1m
Mixed Color
RGB
Pixel Matrix
40 X 1
Agreement
DMX512&Art-Net
Art-Net CH
120
Shell
Plastic and Metal
Frequency
50-60Hz
Surface Treatment
Black Matt
Power and Data Connection
Cat-5 Network Port Signal/Power Input and Output
Cooling
Active
DMX
3-Pin & 5-Pin XLR in/out
Transport Package
Carton/Flycase
Specification
Packing size: 110*3.5*15cm / 2.0KGS
Trademark
MSLighting
Origin
Guangzhou, China
HS Code
94054090
Production Capacity
500PCS/Week
Product Description
LED Video Pixel Strip LED video pixel strip is a product with a length of 1 meter and 40 ultra-high brightness SMD5050 lamp. It has a flexible and easy-to-use video effect system with international standard DMX512 & Art-net dual protocol. 40x1 matrix control and single Control, CAT-5 network port input and input, It an save a lot of manual working in the installation and debugging. At the same time, this product can be used together with video pixel strips and video pixel blocks to create a variety of Peculiar shape. This pixel strip can be equipped with a black matte panel to hide the black light. LED Lamp: 40 x SMD RGB LEDs Angle: 120° Brightness: 22 LUX/1m Mixed Color:RGB Pixel Matrix: 40 x 1 Agreement: DMX512&Art-Net Art-Net CH:120 Input voltage and frequency:24V DC Power: 13W Power and data connection:CAT-5 Network port signal/power input and output Shell:Plastic and Metal Surface treatment: Black Matt Protection level:IP20 Cooling:Active Max. ambient temp.:40°C Mini.ambient temp.: 0°C Maxi..case temp.: 45°C High speed strobe effect with 1-25 flashers per second DMX 512, master-slave and sound activated controllable or auto operation 3-pin & 5-pin XLR connectors IN/OUT
