Mining Machine Rt5015h Mobile Scalping Screen

Product Description

Product Description RT5015H crawler type mobile scalping screen is a durable, sturdy, and high-performance equipment designed for handling heavy screening work, no matter rock blasting or large solid waste materials, the RT5015H crawler type mobile scalping screen can easily handle it and provide good finished materials
Wide application range: precise screening of sand and gravel aggregates such as concrete, asphalt, construction waste, and natural stone, as well as screening of raw materials with high mud content or pre-screening of raw materials before crushing.
Detailed Photos
Product Parameters

RT5015H Mobile Scalping Screen
Feeding Device	Max.feeding Size 500mm
	Hopper Volume 6m³
	Feeding Height 4100mm
	Feeding Capacity 500t/h
Screener	Screening Area 5000mm*1500mm
	Number of Sieve Layers 2
Main ConveyingBelt	Belt Width B1000mm
	Power 2*11kW
Coarse Material Conveying Belt	Belt Width B1200mm
	Power 11kW
Medium-Sized Material Corveying Belt	Belt Width B800mm
	Power 7.5kW
Fine Material Conveying Belt	Belt Width B800mm
	Power 7.5kW
Transmission Conveying Belt	Belt Width B1200mm
Whole Machine	TotalPower 62kw
	Total Weight 37t
	Processing Capacity 200-500t/h
	Working Dimension 17.5m×14.8m×4.8m
	TransportationDimension 18.5m×3.8m×3.8m

---
