Tractor Mounted 3 Bottom Plough Furrow Plow

US$80.00-600.00 1 Piece (MOQ)

Basic Info.

Model NO.
1L-320
Farming Policy
Dry Cultivating Machinery
Power Source
Tractor
Operation
Soil Preparation Machinery, Fixed Operation
Traction Type
Hanging
Drive Type
Tractor Driven
Certification
CE
Color
Red
Transport Package
Iron Box
Specification
furrow plow
Trademark
myagro
Origin
Dezhou
Production Capacity
2000 Units Per Year

Product Description

Model unit 1L-220 1L-320 1L-420 1L-520 1L-225 1L-325 1L-425 1L-525
Number of bottoms 2 3 4 5 2 3 4 5
Working width m 0.4 0.6 0.8 1.0 0.5 0.75 1.0 1.25
Working depth mm 200-250 200-250 200-250 200-250 200-250 200-250 200-250 200-250
Overall weight kg 80 115 145 180 125 228 330 435
Matched power hp 12 25-30 30 45-55 25 35 50 65
Linkage Standard three point mounted

Model unit 1l-230 1L-330 1L-430 1L-530 1L-335 1L-435 1L-535 1L-635
Number of bottoms 2 3 4 5 3 4 5 6
Working width m 0.6 0.9 1.2 1.5 1.05 1.4 1.75 2.1
Working depth mm 250 270~300
Total weight kg 197 248 344 430 380 432 520 613
Matched power kp 35 50 65 80 55~65 65~80 80~120 100~120
Linkage Standard three-point mounted
