220V 5 Ton 10 Ton Wire Rope Electrical Hoist for Lifting

Product Description

220v 3 Phase 50hz 2Ton 5 Ton 10 Ton Wire Rope Electrical Hoist For Lifting


Brief Introduction
1.High efficiency and make the most of space.
2.Accurate orientation,highly-efficient operation,improved logistics efficiency.
3.Safe and reliable,monitored operation,easy maintenance.
4.Modularized design,low maintenance cost,perfect spare parts and components services.
Good Quality CD MD Model Wire Rope Hoist Enquiry Information Need
1. Capacity
2. Lifting height
3. Lifting speed and running speed requirement.
4. Power supply
5. Any other special requirement you need,like I beam type

Wire Rope Hoist

Specification	CD:0.5T	CD:1T	CD:2T	CD:3T	CD:5T	CD:10T
Capacity (Ton)	0.5	1	2	3	5	10
Lifting Height (m)	6-12(m)	6-30(m)	6-30(m)	6-30(m)	6-30(m)	9-30(m)
Lifting Speed (m/min)	8	8	8	8	8	7
Running Speed (m/min)	20(30)	20(30)	20(30)	20(30)	20(30)	20(30)
Wire Rope Dia. (mm)	4.8	7.4	11	13	15.5	15.5
Running Beam Model (GB706-88)	16-28b	16-28b	20a-32c	20a-32c	25a-45c	32b-63c
Lifting Power (m/min)	0.8	1.5	3	4.5	7.5	13
Running Power (m/min)	0.2	0.2	0.4	0.4	0.8	0.8*2
Voltage (V)	380(220-660)
Frequency (Hz)	50
Phase (Ph)	3

Chain Hoist

Loading capacity	0.5 ~ 50t
Lifting height	3 ~ 130 m or customized
Lifting speed	Single speed: 6.6 m/min; or customized Variable frequency speed: 0.66 ~ 6.6 m/min; or customized
Working class	M3 ~ M7
Working temperature	-20 ~ 40 ºC Send inquiry
Power supply	AC-3Phase-220//230380/400/415/440V-50/60Hz
Control voltage	DC-36 / 48V
Motor protection class	IP54 IP55 IP65
Control way	Ground handle control(Push button),wireless remote control,cabnient control
Safety device	Buffer,current overload protection,overload device,power failure protection
Application area	Factory,workshop,warehouse,power station,logstic,etc.
Painting color	Yellow,Red or Customzied

European Hoist

Capacity	Working duty	Lifting height	Lifting speed	Rope reeving	Traveling speed	Wheel load	Weight
1.6	M6	6, 9, 12	1.6/10	2/1	2~20	6.1, 6.2, 6.3	300, 335, 370
2.5	M6	6, 9, 12	0.8/5.0	4/1	2~20	9.1, 9.2, 9.3	315, 350, 385
3.2	M5	6, 9, 12	0.8/5.0	4/1	2~20	11.5, 11.6, 11.7	335, 370, 405
6.3	M5	6, 9, 12	0.8/5.0	4/1	2~20	22, 22.1, 22.2	400, 450, 500
8	M6	6, 9, 12	0.8/5.0	4/1	2~20	28, 28.1, 28.2	580, 610, 640
10	M5	6, 9, 12	0.8/5.0	4/1	2~20	34.7, 34.8, 34.9	580, 610, 640
10	M6	6, 9, 12	0.66/4.0	4/1	2~20	34.7, 34.8, 34.9	650, 690, 730
12.5	M5	6, 9, 12	0.66/4.0	4/1	2~20	43.3, 43.4, 43.5	660, 700, 740
3.2	M5	6, 9, 12	0.8/5.0	4/1	2~20	11.9	510, 525, 540
6.3	M5	6, 9, 12	0.8/5.0	4/1	2~20	20.9	632, 652, 672
10	M5	6, 9, 12	0.8/5.0	4/1	2~20	30	871, 896, 921
12.5	M5	6, 9, 12	0.66/4.0	4/1	2~20	40.5	890, 915, 940
16	M5	6, 9, 12	0.66/4.0	4/1	2~20	59.4, 59.7, 60.0	1314, 1348, 1381
20	M5	6, 9, 12	0.5/3.4	4/1	2~20	59.5	1718, 1766, 1814
32	M5	6, 9, 12	0.8/3.3	6/1	2~20	95, 104	2826, 2920, 3091, 3199

Company Profile
FAQ
1. What after-sale service do you provide?
We have professional sales team and technical team for all customer. We can serve 24 hours a day for you.
2. What payment methods do you support?
We have many kinds of payment for your reference ,such as Western Union, Paypal, L/C, T/T and so on.
3. How to delivery the goods?
We often shipment goods by sea,which is cheaper than by air. It depends on your specific requirement.
4. What is your warranty service about machine?
Our machine has one year warranty time, and our engineering team available for oversea service with crane installation, inspection and commissioning.
5. What is your trade terms?
We have EXW, FOB, CIF, CFR for you to choose, and we can change according to your requirements.
6.Why should I choose your products?
We can provide high quality and low price products for you.

---
