Durable Ingersoll Rand RM220kw Industrial Screw Air Compressor

Product Description

Product Description
In the development process of the new RM series products, we adopted a very advanced new host to provide you with a better performance option. By optimizing the rotor profile and many other improvements, the new main engine can achieve an efficiency increase of up to 16%, greatly reducing operating costs. In addition, the new rotor profile also provides ideal displacement, which is 14% higher than the previous model. Smaller specific power means lower equipment investment costs and energy consumption, reducing your overall cost.
RM series compressors all adopt a new high-efficiency host, combined with fixed-frequency IE3 and ECO*-PM permanent magnet variable frequency IE5 energy-efficiency motor technology, which can save you up to 12-30% in electricity costs.
Efficient
The newly designed high-efficiency main engine can increase the efficiency by up to 16%, the gas volume by up to 14%, and achieve long-term reliable operation.
Reliable Our Advantages
1.The three-stage separation system with conical baffles can remove lubricating oil from compressed air to less than 3ppm, thereby protecting downstream equipment and extending filter life, improving productivity and reducing customer maintenance costs.
2. V-shieldTM protection technology uses flat-sealed O-rings to reduce the risk of pipeline leakage.
3. Fixed frequency: equipped with IEC60034-30 standard lE3 high-efficiency motor. The protection level reaches IP55, achieving Class F insulation and Class B temperature rise.
Frequency conversion: equipped with high-efficiency IE5, IP66 oil-cooled permanent magnet variable frequency motor, achieving H-class insulation and B-class temperature rise.
Efficiency/Productivity Advantages
1. Air intake system - adopts large air intake and low pressure drop air filter to effectively reduce the air intake pressure of the unit and improve the efficiency of the unit. Reduce the number of maintenance times, reduce maintenance costs, and boost customer production.
2. The non-welded oil/after-cooler arranged side by side horizontally on the top of the unit reduces deformation and leakage due to thermal stress, improves the reliability of the unit, extends the service life, reduces the number of maintenance times, reduces the customer's cost during the life cycle of the unit, and improves customer satisfaction. productivity.
Intelligent
Luminance series smart controllers can monitor system parameters in real time. The standard IoT function allows you to know the status of the air compressor at any time no matter where you are, and can provide early warning to prevent unnecessary sudden shutdowns that may cause you losses. Product Parameters

Model	Air Flow	Pressure	Power	Noise	Motor Voltage	Dimension	Weight	Electrical protection level	Controller
	m3/min	Mpa	KW	dB(A)	V/Hz/PH	(L*W*H)mm	Kg		Piece
RM30i_A10	4.9	10	30	72-79	400/50/3	1556L×928W×1413H	697	IP55	Le-120
RM37i_A10	5.62	10	37	72-79	400/50/3	1556L×928W×1413H	742	IP55	Le-120
RM45i_A10	6.85	10	45	72-79	400/50/3	1556L×928W×1413H	870	IP55	Le-120
RM55i_A10	8.4	10	55	72-79	400/50/3	1832L x 1249W x 1512H	1233	IP55	Le-180
RM75i_A10	11.3	10	75	72-79	400/50/3	1832L x 1249W x 1512H	1302	IP55	Le-180
RM90i_A10	15.1	10	90	72-79	400/50/3	2455L x 1586W x 1670H	2262	IP55	Le-180
RM110i_A10	18	10	110	72-79	400/50/3	2455L x 1586W x 1670H	2590	IP55	Le-180
RM132i_A10	22	10	132	72-79	400/50/3	2520L x 1598W x 1740H	3159	IP55	Le-180
RS160ie_A10	26.4	10	160	72-79	400/50/3	2520L x 1598W x 1740H	3234	IP55	Le-180
RM185i_A10	32.4	10	185	72-79	400/50/3	4076 L x 1930 W x 2102 H	4805	IP55	Le-180
RM220i_A10	38.8	10	250	72-79	400/50/3	4000 L x 1930 W x 2146 H	5584	IP55	Le-180
