Automatic Woodworking Hard Wood Plywood Veneer Rotary Peeling Lathe Machine

Product Details

Product Description

Product Description
Hard Wood 4FT Plywood Veneer Peeling Machine
1. Fearures
Spindleless veneer peeling machine is used for make veneer .
And it is suitable for the eucalyptus, pine, cotton wood and another log.
The quality of the veneer determines the quality of the plywood, so controlling the quality of the veneer is the premise and the most important part of producing standard plywood.
veneer peeling machine is a very technical equipment in plywood line equipment.
2. Technical Parameters

DESCRIPTION	UNIT	PARAMETERS
Log peeling length	mm	970mm—1270mm
Log peeling diameter	mm	500mm—80mm
Veneer thickness range	mm	0.6mm—5.0mm
Linear speed of host machine	m/min	60M/Min
Motor powers	KW	Double roller 11Kw Single roller 5.5kw+5.5kw Feeding motor 7.5KW(Servo motor) Clipper motor 1.5kw(Servo motor) Conveyor 1.5kw
Speed reducer		R87 harden helical gear reducers
Rollers specification	mm	Ø125mm x 1500mm (Harden chroming thicker)
Machine overall size	mm	3500mm x 1800mm x 1500mm
Machine weight	kg	5000kgs
Main function	Final veneer automatic cutting function Japan smc guide rail air cylinder Japan NSK bearings Ø90mm Alloy screw and tin bronze nut Harden full closed oil immersion guide bars (Free maintenance)

3. Product Show
4. Contact

---
