4 Port Repeater Poe Extender

Product Description

4 Port 10/100/1000Mbps POE extender switch
4GE POE+1GE PD ports
Product Description:
The TS06P-4GPD-AT is a full Gigabit unmanaged POE expander switch, which provides four POE ports and one PD port. The PD port can get power from any 802.3af/at/POE++ device. Among them, port 1-4 follows the 802.3af/at standard and supports maximum power output of 30w. And the POE ports of the switch can automatically detect and supply power to the PD devices that complies with the 802.3af/at standard. Otherwise, there is no power supply output. In addition, the switch supports auto-negotiating traffic control functions and is compatible with terminal devices of 10Mbps, 100Mbps and 1000Mbps.
The TS06P-4GPD-AT adopts plug-and-play design, which eliminates the need for software settings, which greatly facilitates the installation and use of digital monitoring and wireless coverage.
The TS06P-4GPD-AT is usually used to provide power and data transmission for IP cameras, wireless APs, bridges, and IP phones. The switch can get power from POE injector or switch which connect to the PD port.
Product Features:
Comply with IEEE 802.3, 802.3i, 802.3u, 802.3ab, 802.3x, 802.3q, 802.3af/at protocol. 5*10/100/1000Mbps interface, support for auto-negotiation. 4*10/100/1000Mbps POE interface, support 802.3af/at standard, maximum 30w power output. 1*10/100/1000Mbps 802.3af/at/POE++ PD port which can get power from POE injector and switch. Adopt high-speed Store-and-Forward transmission mode. Support 9k jumbo frames Auto MDI-X function, self-adjusting straight-through line, cross-line connection. 2K Mac address table One DIP switch supports port isolation setting. Port status LEDs
Product Specifications:

Model		TS06P-4GPD-AT
Port	1000M POE	4
	1000M PD	1
Performance	Store and forward	Support
	Switching Content	10G
	MAC Table Size	2K
Usage environment		Operating Temperature:-20ºC~60ºC Storage Temperature:-40ºC~80ºC
		Working humidity:10%~90% RH Non-condensing Storage humidity:5%~90% RH Non-condensing
POE Standard		IEEE802.3af/at per port maximum 30W
Power Input		POE in IEEE802.3af/at MAX 30W AC Input 52V 1.25A(As a POE switch)
Supported Standards and Protocol		IEEE 802.3 Ethernet Media Access Control Protocol IEEE 802.3i 10BASE-T Ethernet IEEE 802.3u 100BASE-TX Fast Ethernet IEEE 802.3ab 1000BASE-T Gigabit Ethernet IEEE 802.3af/at power supply through Ethernet data line pairs IEEE 802.3x Flow Control IEEE 802.1q VLAN Bridge Operation
Operation Mode		Standard sharing, Port isolation (via DIP switch setting)
Data Transfer Rate		Ethernet 10Mbps half-duplex, 20Mbps full duplex Fast Ethernet 100Mbps half-duplex, 200Mbps full duplex Gigabit Ethernet 2000Mbps full duplex
Network Media		10Base-T:2 pair (Cat3) or above UTP/STP (≤150m) 100Base-TX:2 pair(Cat5)or above UTP/STP(≤150m) 1000Base-T:4 pair Cat5e)or above UTP/STP(≤150m)
Dimension		140*80*28mm
Safety Regulations		FCC,CE,RoHS-Compliant

---
