P2.5 P3 P4 P5 P6 Indoor Outdoor Full Color Rental RGB Advertising LED Display Panel Large Video Wall Screens Thin Waterproof Display Panel Billboard Module

Product Description

P2.5 P3 P4 P5 P6 Indoor Outdoor RGB LED Display Panel Video Wall Screen
Feature:
○ High definition videoes and pictures, you will like it ;
○ Cabinets can be customized to a different dimension ;
○ Both for front service and rear service with magnets;
○ Using a silent fan, no noise;
○ Refresh is very high can up to 3840 HZ ;
○ Wide viewing angle, H:140°, V:140° ;
○ Easy to install: Stacking installation design enables easier installation.
Parameter:

Items	P2.5mm	P3mm	P4mm	P5mm	P6mm	P10mm
Pixel	1R1G1B	1R1G1B	1R1G1B	1R1G1B	1R1G1B	1R1G1B
Configuration	SMD 3-in-1	SMD 3-in-1	SMD 3-in-1	SMD 3-in-1	SMD 3-in-1	SMD 3-in-1
Pixel Pitch	2.5mm	3mm	4mm	5mm	6mm	10mm
Pixel Density	160,000	111,111	62,500	40,000	27,777	10,000
Module Size(mm)	160x160	192x192or 192x96	256x128	160x160or 320x160	192x192 or 384x192	320x160
Pixels/Module	64x64	64x64or 64x32	64x32	32x32or 64x32	32x32or 64x32	32x16
Cabinet Size(mm)	960x960	960x960	1024x1024	960x960	960x960	960x960
Pixels/Cabinet	384x384	320x320	256x256	192x192	160x160	96x96
Cabinet Weight	37KG	37KG	42KG	37KG	37KG	37KG
Brightness	1300cd/	1300cd/	1300cd/	1300cd/	1300cd/	1000cd/
Viewing Distance	>2.5m	>3m	>4m	>5m	>6m	>10m
Power Consumption	Max: 800	Max: 800	Max: 650	Max: 400	Max: 400	Max: 300
(W/)	Ave: 240	Ave: 240	Ave: 195	Ave: 120	Ave: 120	Ave: 100
Driver Mode	1/32 scan	1/16 scan	1/16 scan	1/16 scan	1/16 scan	1/8 scan
Cabinet Material	Cold Rolled Steel
Refresh Rate	300-3000HZ adjustable
LED Life	100,000 hours
Supply Voltage	AC220V/50HZ; AC110V/60HZ
Operating Temperature	-20ºC ~ +40ºC
Operating Humidity	10% - 90%
Viewing Angle	H: 120°; V: 120°
Gray Scale	Red, Green, and Blue each 16K
Display Color	4096 Billion
IP Rating	IP20
Display Capability	Text, Graph, and Video
Notes: Specifications are for reference only. Please contact our salesperson for details. All rights are reserved to Led World.

Project case:
Product testing:
Product detail:
Workshop:
Product installation:
Control system:
Products related:
LED Display /LED display screen/LED sign/LED video wall
1. Model No.: P1.66,P1.8,P1.9, P2,P2.5, P3, P4, P5, P6, P7.62, P8, P10, P12, P16, P20, P25 etc
2. Display Color: 256*256*256
3. LED Chips: Opto, Epistar, Silan, Huacan, Sanan
4. Raw Materials: Toshiba IC, MBI IC, Chuanglian Power Supply, Meanwell Power Supply, Meanwell fans, ADDA fan, Beijing glue, Korean glue.
5. Cabinet: Standard cabinet, simple cabinet, customized cabinet, a cabinet for rental, Iron or Aluminum cabinet, a cabinet for front maintenance, cabinet with lock, special cabinet with Southco Lock, for hung and rental and etc.
6. Package: Flight case, wooden box package & carton box and etc.
7. Guarantee: 2 year
FAQ
1. How can I place an order?
Please provide the details of your requirements as clear as possible. So we can send you the offer the first time. For designing or further discussion, it is better to contact us with Skype/email /phone, in case of any delays.
2. What kind of display we provide?
We have indoor/outdoor/rental taxi top /mobile LED display/LED stage/Irregular LED display for you to choose from.
3. Are you a manufacturer of led displays. If yes, in which city?
Yes, Our factory with 2000 square meters. And we're in SHENZHEN city, GUANGDONG Province.
4. How long can I get the goods?
Our production time is about 10-25 working days. When you confirmed the order, we can start production after receiving your deposit(30% TT in advance). we will update the production details in time. we will notice you that we can deliver the goods to you after we get full payment.
5.May I know the package details?
For fixed installation, we use a wooden case, usually 2 or 4 cabinets in 1 wooden case;
For the rental market, we suggest you use a flight case, generally 8 cabinets in one flight case.
It's safe to protect the screen on the way, also economical.

6.What is the payment method?
We support a variety of payment methods, the most common is the TT.
7. What's the pixel pitch for Outdoor LED Display Screen?
Outdoor (p3.91mm/p4.81/p5mm/P6mm/ p6.25 /p6.67/ P8mm/P10mm/p16mm/p20mm) led display screen
8.Can it play HD video?
Yes, it can realize HD video function with Linsn/nova controlling system

9.What's the controlling system?
Our standard controlling system for this model is Linsn/ Novastar. Also support another controlling system, like Xixun, TF, Colorlight, etc.
10.What's the difference between DIP(1R1G1B) and SMD(One LED, 3 in 1)?
SMD(One LED, 3 in 1) LED Display, one pixel has one LED lamp, 3 led chips in one LED Lamp;
Traditional DIP( 1R1G1B) use 3 LED Lamp in one pixel.
SMD(One LED), reduced the LED on the screens, reduced grainy of the screen, and improve the uniformity of the screen, this will make the screen have a more wide viewing angle and smooth image. With the technology advanced and SMD brightness improved, SMD is more and more used outdoor.
11. What are your terms of delivery?
We accept EXW, FOB, CFR, CIF, DDU, DDP, etc. You can choose the one which is the most convenient or cost-effective for you.
