High Quality and Competitive Price Stainless Steel 316 Check Valve 2 Inch

Product Description

Product Description
Check valve RHD/RHV/RHZCheck valves RHD, also known as high pressure check valves, are available with
BSP female thread (DIN ISO 228)
BSPP threaded ED seal (ISO 1179)
UN/UNF female thread (SAE J 514)
24° tapered light connection (DIN 2353)06L-42L
24° tapered heavy connection (DIN 2353)06S-38S
Pressure range up to 420 bar/6000 PSI,
Working temperature range: -20°C to +100°C.
The standard opening pressure : 1 bar with ±20% variation, but a wide range of opening pressures is also available on request. Products Details

Product Standards:	DIN2353/ISO8434
Product Materials:	Carbon steel/stainless steel
Surface Finish:	White zinc/zinc-nickel alloy
Thread:	NPT SAE BSP ORFS metric thread
Product Features:	Sealing is achieved by means of a 90° tapered spool and a synthetic sealing ring in conjunction with a tapered seat, the spool opening is positioned so that it opens reliably, with low vibration and low noise levels.
Application:	Hydraulic systems are particularly suitable for construction, agricultural, mining and painting machinery, but also for steam and oil and gas media (but please note the choice of sealing material)

Detailed Photos

Series	D1	T1	CFDN	71DN	D3	CFL1	71L1	L2	L3	L4	S1	CFS2	71S2	S3	Weightg/piece	Order number	Working pressure (bar)
																	CF	71
L	0608101215	G 1/8AG 1 1/4AG 1 1/4AG 3/8AG 1/2A	3.55.57.59.511.0	3.55.57.59.511.5	1419192227	35.037.046.050.053.0	35.037.045.549.552.5	28.030.038.542.545.5	812121214	42.544.553.057.060.5	1719222727	1719243032	1719243032	1417192227	4762105175205	RHV06LREDOMDRHV08LREDOMDRHV10LREDOMDRHV12LREDOMDRHV15LREDOMD	400400400400400	250250250250250
	1822283542	G 1/2AG 3 1/4 AG 1AG 1 1/4AG 1 1/2A	14.018.023.029.029.0	14.018.023.029.029.0	2732405055	58.063.071.080.080.0	57.562.570.579.579.5	50.055.063.069.068.5	1416182022	66.071.079.590.091.0	3641506065	4146556570	3646556070	3236415060	29445072010501560	RHV18LREDOMDRHV22LREDOMDRHV28LREDOMDRHV35LREDOMDRHV42LREDOMD	400250250250250	160160100100100
S	0608101214	G 1 1/4AG 1 1/4AG 3/8AG 3/8AG 1/2A	3.53.55.57.59.5	3.53.55.57.59.5	1919222227	38.538.545.548.553.0	38.538.545.548.552.5	31.531.538.041.044.5	1212121214	46.046.054.057.062.0	1919222427	1919242732	1919242732	1719222427	7379132153230	RHV06SREDOMDRHV08SREDOMDRHV10SREDOMDRHV12SREDOMDRHV14SREDOMD	420420420420420	400400400400315
	1620253038	G 1/2AG 3/4AG 1AG 1 1/4AG 1 1/2A	11.015.019.024.029.0	11.515.019.024.029.0	2732405055	57.063.0-78.086.0	56.562.566.577.585.5	48.052.054.064.069.5	1416182022	66.073.578.590.0100.0	3241466065	3650556070	3646506070	3036465060	29351164811761624	RHV16SREDOMDRHV20SREDOMDRHV25SREDOMDRHV30SREDOMDRHV38SREDOMD	420420420250250	315250250250250

Company Profile
Ningbo Fuke Hydraulic Machinery Co., Ltd. is a specialized company dedicated to the production and research and development of hydraulic fluid connectors and control valves. The company mainly provides hydraulic fitting, high-precision hydraulic valve blocks, high-pressure ball valves, and check valves that meet ISO, DIN, and SAE standards.
The company has experienced hydraulic system designers, who can provide customers with relevant technical support and all hydraulic accessories solutions to improve customer procurement efficiency.The company earnestly implements the 1S09001:2000 quality system, and its products are widely used in metallurgical industry, drilling platform equipment manufacturing, construction machinery, wind power generation, petrochemical industry, machine tool manufacturing
Producing Department
Inspection Area Warehouse
Our Advantages 1. Raw material, 100% testing before delivery, 99% no leakage, and wonderful torque.
2. Have cooperated with a lot of importers all over the world.
3. Experienced in doing business with big customers as per high standard request
4. Quick and stable delivery time
5. Professional R&D Team.
6. Free samples could be sent by request.
Certifications
FAQ1. Can I get a Sample?
We do provide some small specific samples accordingly based on the process we situate in.
2. Do you provide customized products?
We are good to offer customized services in terms of logo labeling, manufacturing based on samples or blueprints, etc.
3. Will communication be a problem?
Our sales team had great knowledge of our products and acquired solid English communication skills in both written and speaking; the communication can be accessed either literally or verbally via any social networking platform.
4. Payment Method.
L/C, T/T, PayPal, Western Union, etc. Principally we do not accept third-party transactions via China's mainland region channel.
5. Why Choose us?
Quality: 100% leakage, material, and functionality test in process and before shipping.Variety: Highly customizable flexibility. Reliability: 5 years of manufacturing experience.Efficiency: Quick& Effective response.Utility: We are Manufacturer.Flexibility: OEM/ODM are provided.Authentication: Real-time plant audit provided.Competitiveness: Price is negotiable on large volumes.

---
