Corrugated Sheet Making Machinery Zinc Sheet Making Machine

Product Description

Product Description
Corrugated Roof Sheet roll forming machine
The handwheels can adjust the feeding coil thickness.
Our roof sheeting Roll Forming Machine for different models based on different designs or customer's samples . It is a machine produce building material of metal roof, the products are widely used as the roof and wall of factory,warehouse, garage, gymnasium, exhibition center.It has many advantages, such as easy installation, short building period, beauty, light weight but high strength. Detailed Photos

We can follow your requests to make the machine, the profile drawings we displayed here are the model type.
Other profile sizes are also available for us.
Here is the attachment with some pictures of our products that may suit your requirements,please check and select the products that you are interested in.
For other profiles,please send me pictures or drawings.I will send you best offer accordingly.
Main Features
[High Efficiency]6m per minute.Produce 2880m per shift for 8 hours one day.
[Long Life Machine]Rollers of machine are CNC machine tooled, plated with 0.05mm hard chrome on surface.Heat treatment for cutting frame to remove the steel stress, to avoid deformation. Cutting material is Cr12 mould steel with quenched treatment, all these processing steps ensure machine long life time.
[High Precision]Shafts for rollers are tooled by grinding machine at least twice. Rollers are CNC processed to ensure precision performance.
[Automatic & Easy Operate]Safe and easy to operate with Mitsubishi PLC touch screen operating system.Friendly man-machine interaction.
[Excellent Services]Technician can be sent to your factory to install the machine and train your workers. Engineers are able to service overseas.We supply lifetime services for our machines.
Product Parameters
Main parameters of the roll forming machine

Item	Name	Description
1	Decoiler	Capacity:5 tons
2	Material	Steel Coil
3	Thickness	0.3-0.8mm
4	Transmission	Chain/Gear/Gearbox
5	Speed	10-15m/min
6	Roller	Steel with quenched treatment,chromed on the surface
7	Shaft	steel with tempering treatment
8	Cutting type	Hydraulic cutting
9	Cutting material	Cr12 with quenched treatment Hardness58°-62°
10	Welding	Automatic spot welding
11	Control system	PLC
12	Electric brand	Delta,Siemens,Schneide
13	Voltage	380V,50HZ,3PH(or as customers' request)

Sr. No	Optional Component	Quantity
01	Hydraulic Coil Decoiler	1Set
02	Coil Car	1Set
03	Auto Stacker 20 Ft. Length	1Set
04	Electrical Coil Decoiler	1Set
05	Telescopic Type Machine Guard	1Set

1.How to maintain the machine?
Answer: add mechanical lubrication equipment to chain, bearing and cutting slide every month. Add mechanical lubrication to the case every half a year.
2. Do you sell only standard machines?
A: No, most of our machines are built according to customers specifications, using top brand name components.
3.How many workers to operate the machine?
A:Only 1-2 workers.
4. How to visit your company?
a.Fly to Beijing airport: By high speed train From Beijing Nan Station to Cangzhou West Station(1 hour), then we can pick you up .
b.Fly to Shanghai Airport: By high speed train From Shanghai Hongqiao to Cangzhou West station(4.5 hours), then we can pick you up.
5. What can you do if the machine broken?
Our machine's warranty period is 12months,if the broken parts can't be repaired,we can send the new parts to replace the broken parts for free,but you need pay the express cost yourself.if over warranty period,we can for to solve the problems via negotiation,and we supply the technical support for the whole life of the equipment.
6.How can I trust you that machines pasted testing running before shipping?
A: 1) We record the testing video for your reference. Or,
2) Please visit company and test machine if convenient.

---
