US$6.60
100-499 Square Meters
US$6.30
500+ Square Meters
Basic Info.
Water Absorption
1.5%~3.5%
Contraction Percentage
<0.4%
Tensile Strength
81~130MPa
Coating
Anti-Scratch, Anti-Fog, Anti-Static, Anti-UV
Application
Windows, Machine Cover, Windshield
Transport Package
Wooden Pallet
Specification
1220 x 2440 mm / sheet, 2050 x 3050 mm/sheet
Production Capacity
1000 Ton /Day
Product Description
We are manufacturing both Polycarbonate or acrylic sheets.
| Material | Polycarbonate sheet | Acrylic sheet |
| Size | 1220 x 2440mm , 1000 x 2000mm | 1250 x 2460mm, 2000 x 3000mm |
| Color | Transparent, brown, blue, yellow, green, customized | Clear, white black, brown, blue, yellow, etc. |
| Application | Greenhouse, windshield, roofing, awning, machine guard | Display, covers, signages |
| Coating | Anti- scartch, anti-fog, ESD anti-static, anti-UV | Anti- scartch, anti-fog, ESD anti-static,etc |
Our production lines : Polygood plastic use 100 % new and Bayer resins which are UV stabilized so our polycarbonate sheet has better performance for outdoor use,
we cut polycarbonate sheet in any sizes or shapes based on drawing from customer. It can be cut, routed, drilled, and milled.
Polycarbonate features:
High impact resistant & excellent light transmission to 91 %, Fire-resistant grade to V2-V0 Strong, durable & Light weighted Good performance for bending, drilling, milling, thermoforming, printing. Weather-resistant, application temperature range at -40ºC ~130 ºC Good electrical insulation UV stabilized
Polycarbonate Technical data :
| Characteristics | Unit | Data |
| Impact strength | J/m | 850 |
| Light Transmission | % | 90 |
| Specify Gravity | g/m³ | 1.2 |
| Coefficient Thermal Expansion | mm/m.ºC | 0.063 |
| Service Temperature | ºC | -40ºC~125ºC |
| Heat Conductivity | w/m²ºC | 0.2 |
| Flexural strength | N/mm | 2100 |
| Flame Resistance | UL-94 standard | V2, V0, HB |
| Tensile Strength | N/mm² | >60 |
| Modulus of Elasticity | Mpa | 2400 |
Potential Applications:
Display Guards Barrel vaults Domes Conservatories Windows and doors
Advantages of Polygood Scratch Resistant polycarbonate sheet:
Better scratch-resistant features ( HB, 1H, 2H, high wear-resistant ) Better abrasion-resistant performance (2500 cycles) Better optical visibility ( 89% ) Much more cost-competitive ( Factory directly ) Thermoformable to any shapes Anti-fog as an option
Polycarbonate solid sheet Abrasion resistant test:
Polycarbonate sheet cut to size & CNC machining center : Cut to size & shape Cold bending & hot bending Engraving & milling Drilling & gluing Laser cutting & polishing Thermoforming Silkscreen printing & UV printing Laminating ( Acrylic & polycarbonate )
Packaging & shipment:
>>
