| Model | BDW-86L390 | BDW-86L490 | BDW-86L650 | BDW-86L770 |
| Temperature range ºC | -50-86 |
| Nominal capacity [Liters] | 390 | 490 | 650 | 770 |
| Exterior dimensions mm WxDxH | 909×797×1990 | 909×929×1990 | 1091×929×1990 | 1091×1053×1990 |
| Interior dimensions mmW1×D1×H1 | 589×505×1310 | 589×637×1310 | 780×637×1310 | 780×760×1310 |
| Door opening mmW2×H2 | 589×1310 | 589×1310 | 780×1310 | 780×1310 |
| Insulation thickness mm | 126 |
| Fxterior finishing | White plastic coated galvanised steel |
| Interior finishing | Stainless steel |
| Inner door | 4 |
| Shelves | 3 |
| Levels | 4 |
| Racks [boxes] | 16(240) | 16(320) | 20(400) | 20(500) |
| Ring latch hole | Yes |
| Mechanical lock | Yes |
| Data logger | Yes |
| Battery | Yes |
| Interior chamber temperature probe | Yes |
| Vent port | Yes |
| Gasket heating | Yes |
| Controller type | Touch screen |
| Refrigerant type | Non HCFC |
| Voltage/Frequency [V/Hz] | AC220 /50 |
| Power [W] | 1500 | 1800 |
| Net Weight [kg] | 318 | 332 | 410 | 490 |
| High condenser temperature alarm | Yes |
| Power failure alarm | Yes |
| Temperature sensor failure alarm | Yes |
| Low battery alarm | Yes |
| High / Low temperature alarm | Yes |
| Door open alarm | Yes |
| Sound pressure [dB] | ≤53 |
| Cooling time [h] | ≤6 | ≤8 |
| Temperature uniformity ºC | ≤6 |
| Certification | CE /RoHS |
