Three Axies 250CNC Efficient Surface Grinding Machine Tool for Workshops

Product Description

250/2550CNC Surface Grinding MachineThree Axies 250CNC Multifunction Grinding Machine Tool
We adhere to a dynamic policy of continuous enhancement across our entire product line, proudly reserving the right to refine specifications, mechanics, or designs at any moment without prior notice or obligation.

	parameter	unit	CNC-250	CNC-2550
general picture	Table size (x*y)	mm	200×500	250*500
	X axis travel	mm	580	580
	Y axis travel	mm	230	280
	Max center of wheel to table	mm	380	380
	Maximum load	kg	200	200
Table	Table T cell specification	mm×N	14×1	14×1
	Table speed	m/min	0-25	0-25
Y axis	Minimum feed	mm	0.001	0.001
	Single feed		0.1~10	0.1~10
	Fast moving speed	mm/min	0~1200	0~1200
Z axis	Minimum feed	mm	0.001/0.01	0.001/0.01
	Fast moving speed	mm/min	0~800	0~800
grinding	grinding wheel size max	mm	Φ200×Φ31.75×19
	grinding wheel speed	R.P.M	0~3600	0~3600
motor	spindle motor	HXP	2×2	2×2
	the Z axis motor	W	750	750
	the Y axis motor	W	750	750
	the X axis motor	W	1500	1500
	cooling motor	W	90	90
Size	height of machine	mm	2000	2000
	floor space	mm	2000×1350	2000×1450
	weight(about)	kg	1450	1550

Cheng Yu Machinery Technology Co., Ltd. was founded in Dongguan City, Guangdong Province, drawing on a rich legacy of over 30 years in grinding machine manufacturing from Taiwan, supported by a wellspring of technical expertise. In the fast-paced world of CNC machine tools, the focus has shifted towards high-speed, high-precision, and innovative technologies. The trend embraces a composite approach, intelligent systems, open architecture, parallel drive, seamless networking, and eco-friendly solutions that mark the future of CNC machine tools. Dongguan Chengyu Machinery Technology Co., Ltd. stands as a beacon in the realm of machine tool production and processing, as well as machine tool accessories. Upholding a business ethos anchored in 'technology, innovation, reliability,' we champion a 'meticulous' quality policy aimed at delivering superior products and exceptional customer service. Our process begins with a deep dive into customer requirements—evaluating their production processes, technology, and quality demands. With an unwavering commitment to designing and manufacturing, we continually enhance product applicability, venturing into expansive numerical control domains. Our product positioning aligns with high automation, precision, and quality, underpinned by a comprehensive and scientific quality management system, cutting-edge equipment, and unrivaled craftsmanship. In catering to market demand, Chengyu Machinery excels in crafting high-precision CNC surface grinding machines, CNC forming machines, four-axis punch grinders, vertical slider grinders, and gantry rail grinders. We also specialize in the design and manufacture of industrial robots, automated production lines, and integrated applications. Here's a concise overview of our CNC grinding machine series: I. HS series 618 / 250 / 3060 / 4080 / 40100 (available in both servo and hydraulic types) Processing capacity: Engineered for surface grinding and grooving applications. Features an innovative patented hydraulic control system (hydraulic type). Functionality: Comes with specialized grinding programs for flat surfaces and groove cutting. Versatile feed mode: Options for front, back, left, or right, with each grinding program retaining memory of the feed mode. Built-in protection: Grinding wheel overload triggers automatic shutdown. II. (servo type / hydraulic type) Processing capacity: Advanced surface grinding, grooving, and integrated scheduling. Incorporates our state-of-the-art patented hydraulic control system (hydraulic type). Functionality: Equipped with a diverse array of grinding programs including surface grinding, groove cutting, sole grinding, side grinding, and tailored displacement grinding. Grinding wheel dressing: Offers bottom plane dressing, adjusting to set parameters for rough and fine grinding, with automatic dressing and compensation during the grinding cycle. Feed mode flexibility: Front, back, left, or right selection is possible, with each grinding program retaining memory of the feed mode. Capabilities include equidistant grooving and complex unequal patterning. 3. Four-axis CNC grinding machines, available in both horizontal and vertical configurations. Processing versatility: Capable of arbitrary equal division and selective tooth processing. Easily handle waist circle operations by entering AB size. Specialized in triangle fillet operations—input inscribed circle size B and fillet size R. Achieve precision with quadrilateral fillet operations—input side lengths A, B, and fillet size R. Craft eccentric circles by specifying eccentricity along with starting and ending diameters. Perform circular operations by entering starting and ending diameters. Arc: Seamlessly input the desired arc size and specify the precise rotation angle to achieve exceptional precision in your projects. Step difference and rotation profile: Customize with exactitude, adapting to unique contours, ensuring optimal performance and exceptional results. Processing schedule: Effortlessly save your meticulously crafted processing schedule as a reusable file, enabling quick retrieval and efficient repetition for future tasks.

---
