| 1. It is mainly used for harvesting Root crops or fruit like potatoes, carrots, garlic etc. | |
| 2. With no grass blocking or clod leakage during working. | |
| 3. The anti-grass winding function of the machine enables harvesting with seedlings without any blocking. | |
| 4. The residual agricultural film can be extracted so as not to affect the next crop's growth | |
| 5.The working principle is that the digging shovel digs up the soil and crops through the impetus of the tractor.And the digging shovel make crop and soil separate through vibrationsieve,the soil first drip down from the clearance of vibration sieve, finally the crop crashed down on to the road from the back | |
| Model | YCX-22 |
| Row number/working mode | Single row(60-80cm) |
| Row spacing(cm) | 55-80 |
| Productivity(m^2/h) | 2000-2500 |
| Total weight(kg) | 105 |
| Matched power (hp) | 8--18 hp walking tractor |
| Working depth (cm) | 20 |
| Working width (m) | 0.6-0.8 m |
| Gain rate (%) | ≥96 |
| Loss rate (%) | ≤2 |
