| US$59,000.00 | 1 Piece (MOQ) |
| Engine:Cummin-s/4BTAA3.9-C125 Power:92kw/2200rpm Overall weight:13000kg | ||
| More reliable & stable New design chassis offers stable structure Popular major components(Engine,motor,valve & pump) Continious power & higher economy Low fuel consumption & continious power Various attachments are available Working models selectable More comfort & higher safety Low-noise & wide spacious cab with a/c Long design boom & hydraulic pipes for hammer(Optional) Different size buckets available |
| Overall Dimensions | |
| Shipping Length | 7800mm |
| Shipping Height | 2900mm |
| Overall Width | 2500mm |
| Tail Swing Radius | 2400mm |
| Track length | 3470mm |
| Boom length | 3700mm |
| Arm length | 2100mm |
| Fuel Tank | 220L |
| Hydraulic oil tank | 180L |
| Operating Range | |
| Max dig Height | 8600mm |
| Max dump Height | 6130mm |
| Max dig Depth | 5500mm |
| Max dig Radius | 8160mm |
| Engine | Cummin-s 92KW/2000rpm |
| Hydraulic System pressure | 32Mpa |
| Hydraulic System flow | 130*2L/min |
| Bucket Volume | 0.6m3 |
| Bucket digging force | 85KN |
| Arm digging force | 53KN |
| Rotation Speed | 13-14rpm |
| Travel Speed | 2.3/4.5km/h |
| Approximate Weight | 14000kg |
