Product Details
Product Description
Product Description
Jinan Diesel Engine CO.LTD(JDEC) is the only international-combustion engine manufacturing enterprise belonging to China National Petroleum Corporation(CNPC).It is also the manufacture of off-highway medium&large power engine in China.At present,it covers area 600,ooom2 and has more than 2000 employees.The total asset is more than 800 million.In 1995,JDEC got the CCS ISO 9001 quality system approval.In 1996,it was listed in Shenzhen Stock Exchange as Shiyoujichai.
The main products named Jichai include diesel engines,diesel gensets,gas engine and gas gensets.Jinan Diesel Engine CO.Ltd(JDEC) has begun to develop Series 190 Marine diesel engines since the beginning of 1980s which have been enlarged for several hundred models,such as 16V,12V,8V,6L,4L,ect.The power range is from 160 to 2400KW while the speed are 1000rmp,1200rmp,1300rmp,1450rmp and 1500rmp separately.These engines are widely applied for all kinds of vessels and power take off equipments,such as,naval vessels,fishers,dredgers,passenger liner,freight liner,oil vessels,engineering vessels,ect,which are sold to many areas and countries of Southeast of Asia,South American or North Africa.
Main technical data
No. and arrangement of cylinders:8-cylinder,in-line
Type:Four stroke,water cooled,turbocharged and aftercooled,direct injection
Bore:190mm
Stroke:210mm
Total displacement:47.6L
Compression ration:14.5:1
Direction of rotation:Counter-clockwise engine without R,clockwise engine with R in the model(facing to flywheel)
Starting method:Air motor or electric motor
Lubricating method:Pressure and splash lubrication
Jinan Guohua Green power Equipment Co.Ltd,a distributor of JDEC,established in 2006.Ten years development and growth,it has became one of the main distributor of JDEC with the advantage of lower price,better quality and best service.We hope we could get your acknowledgement through our honesty and strive.If you are interested in our product,please give us a chance also give you another way.
Contact way:
Tel;18766952912,0531-8560071
Email:1356782504@qq.com
Website: /
Here are the models and main technical specifications of some types.
Model
Item
| 8190ZLD
| 8190ZLCZ-R
| 8190ZLCZ-1R
| 8190ZLCZ1-1R
| 8190ZLCZ1-2R
| 8190ZLCZ1-3R
|
8190ZLC
| 8190ZLC-1
| 8190ZLC1-1
| 8190ZLC1-2
| 8190ZLC1-3
|
Type
| Four stroke,direct injection,water cooled,turbocharged and inter cooled
|
No.Of cylinders
| 8
|
Cylinder arrangement
| In line
|
Cylinder bore (mm)
| 190
|
Piston stroke
| 210
|
Total piston displacement
| 47.63
|
Compression ration
| 14.5:1
|
Rated power (KW)
| 720
| 720
| 600
| 490
| 500
| 650
|
Rated speed(r/min)
| 1500
| 1450
| 1200
| 1200
| 1000
| 1300
|
One hour power (kw)
| 800
| 792
| 660
| 539
| 550
| 715
|
One hour speed (r/min)
| 1500
| 1496
| 1239
| 1239
| 1032
| 1342
|
Min stabilized operating speed (r/min)
| 650
| 650
| 540
| 540
| 400
| 580
|
Min stabilized operating speed(r/min)
| ≤600
|
Specific fuel consumption(g/kw.h)
| ≤204
| ≤202
|
Specific oil consumption(g/kw.h)
| ≤1.2
|
Max firing pressure(Mpa)
| 12
|
Mean effective pressure(Mpa)
| 1.2
| 1.251
| 1.26
| 1.03
| 1.26
| 1.26
|
Mean piston speed(m/s)
| 10.5
| 10.51
| 8.40
| 8.40
| 7.00
| 9.10
|
Stabilized speed droop(%)
| ≤8；For generating set≤5
|
Exhaust temperature before turbine(°C)
| ≤600
|
Oil pressure in main passage(KPa)
| 300~600
|
Oil temperature in main passage(KPa)
| ≤90
|
Net weight (kg)
| 4500
|
Overall dimension(L*W*H)
| 3175*1208*2055
|
>>
