Plastic Pet/PP/HDPE/LDPE/LLDPE/ABS/PS/PVC/PC/BOPP Bottle/Film/Bag/Drum/Pallet/Pipe/Container/Box/Jar/Barrel Washing Line Crushing Plant Recycling Machine

Product Description

Plastic Pet PP HDPE LDPE LLDPE ABS PS PVC PC BOPP Bottle Film Bag Drum Pallet Pipe Container Box Jar Barrel Washing Line Crushing Plant Recycling Machine
Product Description
Zhangjiagang Retech Machinery Co.,Ltd is specialized in the R&D,design,manufacture and sales of different kinds of plastic recycling equipments. Our main products include plastic washing recycline line, plastic pelletizing recycline line and auxiliary machines. With rich industry experience and advanced processing technology, we provide customized plastic recycling solutions to global customers.
1. PP PE Film Washing Line:
PP PE film recycling washing line is mainly used to deal with various plastic LDPE agricultural film, LLDPE wrap film, PP woven bags and other plastic materials after consumption. The plastic film is completely cleaned by efficient crushing system, continuous washing and powerful drying equipment. We can provide customized recycling equipment solutions designed according to customer's material conditions.
2.PET Bottle Washing Line:
Plastic PET bottle washing recycling line is used to recycle post-consumer PET bottles. The key point of PET recycling system is the rate of removing the impurities.The higher purity PET flakes will improve the end product and lower the manufacturing cost of next processing.
We could design different PET recycling solutions basis on the requirement of standards on final flakes.
3. HDPE PP Bottle Washing Line:
Our HDPE PP bottle containers recycling washing line is working to process the post-consumer waste and used plastic bottles,cans,bucket,etc. The baled opener will make the plastic bricks into loose first, double shaft shredder will pre-cut the big plastic tank into small, de-ironing manget separator could remove the irons and protect the blades in crusher.
By constantly crushing ans washing system,the final HDPE PP flakes will be dry and clean.
We need to get below information to prepare an offer:
(1) What's your raw plastic materials?
(2) What's the capacity of machine do you need to process? (kg/hr)
Retech will:
1. Design your own plastic recycling solutions.
2. Send 3-D layout drawing in 1:1 building workshop.
3. Professional sales team service 24 hours online.
Detailed Photos
Product Parameters
PET Flakes Quality Reference:

Mousiture	<1%	Label	<30PPM
PVC	<50PPM	Variegated	<20PPM
Glue	<10PPM	PH	Neutral
PP&PE	<20PPM	Toal Impurity	<150PPM
Metal	<20PPM	Flake Size	Optional

Estimated Plant Space of PET Bottle Washing Plant:

Capacity (kg/h)	Power(kw/h)	Area(m*2)	Labor
500	220	400	6
1000	500	750	8
2000	700	1000	10
3000	900	1500	12

Parameters of PP PE Film Washing Line:

Capacity(kg/h)	Power(kw)	Area(m²)	Labor	Water(m³)
300	130	150	2	5
500	280	300	3	8
1000	425	500	4	10
2000	520	800	4	12

Certifications

Packaging & Shipping

Solution
1000kg/h PE PP Film Woven Bag Washing Line
3000kg/h PET Bottle Recycling Washing Line
2000kg/hr HDPE PP Hard Plastic Recycling Sorting Washing Line Shredder integreted plastic PP PE film woven bag compactor pelletizing line
Single stage Plastic PP PE film pelletizing machine
Double stage design plastic PP PE film rigid flakes die face cut granulating line
FAQ
1. What is the function of PET bottle washing recycling plant?
The PET bottle washing recycling plant is mainly used to process PET beverage bottles. The line includes two functions, one function is to separate the PE caps and PVC or PP caps out to get pure PET flakes finally. The other one function is to wash the PET flakes clean, at end to get clean flakes.
2. What are main parts of the PET bottle washing recycling plant?
The PET bottle washing recycling plant is mainly consists of:
Belt conveyer--- bale opener--- belt conveyer-pre-washer--- belt conveyer--- mechanical label separator--- manual sorting--- metal detector--- belt conveyer--- crusher--- screw conveyer--- floating washer--- screw conveyer--- hot washer--- screw conveyer--- high speed friction washer--- screw conveyer--- floating washer--- screw conveyer--- vertical dewatering machine--- drying system--- zigzag label separator--- storage silo--- operating panel
The up structure of the flowing chart is just a standard we recommend, it can be adjusted due to the customers' material situation and requirements.
3. What capacity of the PET bottle washing recycling plant?
300-3000kg/h for single washing line
4. What power of the PET bottle washing recycling plant?
150kw~350kw
5. How much water does it need of the PET bottle washing recycling plant?
3~8T per hour
6. How large space does it need for a PET bottle washing recycling plant?
100~400 square meters
7. Do you offered training of the PET bottle washing recycling plant?
Yes, we can training your worker.
8. Can you send engineers to our factory to help us install the PET bottle washing recycling plant?
Surely it is no problem.
9. Do you offer all the documents for the PET bottle washing recycling plant? Such as the manual operating.
Yes, we will offer you the complete documents for the PET bottle washing recycling plant.
10. What is the situation of the final products from the PET bottle washing recycling plant?
The PET flakes from the PET bottle washing recycling plant moisture level lower than 1%, the PVC level lower than 200PPM, the dirties level lower than 300PPM.
11. What certifications do you have for the PET bottle washing recycling plant?
We have CE and ISO9001 certification for the entire PET bottle washing recycling plant.
12. What is material of the PET bottle washing recycling plant?
The parts contacted with water are made of stainless steel SUS 304 for the entire PET bottle washing recycling plant.
13. Does it easier and costly to maintenance for the PET bottle washing recycling plant.
It is easier and not costly. We will train your workers and offer the manual operating.
14. What about the electrics of the PET bottle washing recycling plant?
Our standard electric parts are famous brand, such as Siemens Contactor, Fuji inverter… and also they are customized for the PET bottle washing recycling plant.
15 workers needed for the PET bottle washing recycling plant?
4-12 people
