Full Servo Motors Double Line Super High Speed Hot Sealing and Hot Cutting T-Shirt Bag Making Machine with Auto Punching Machine

Product Description

Full Servo Motors Double Line Super High Speed Hot Sealing and Hot Cutting T-shirt Bag Making Machine with Auto Punching Machine
1. Product Description
Feature:
1. Especially designed for hot sealing and cutting of T-shirt bag. It can be punched automatically in two production lines which will increase the production and save the manpower.
2. Double track designs, double production lines, double photo scanners, double servo motors.
3. Photocell for accurate registration of film printing points if the photocell can't catch printing point the machine will stop automatically.
4. Inverter control speed, easy operation, reduce electric consumption.
5. When the output bags reach the setting number, the punch machine will clamp the bags, without stop.
6. New designed sealing blade, when blade need be cleared up, it can be turned 100° And fixed. It will be safe and easy to take care.
7. Strong sealing and output bags being tear up neatly.
8. Punching machine use air and liquid pressurized cylinder, so the noise is low and the gas consumption is little.
2. The Main Technical Parameters

Model	RL-S500×2
Voltage	380V, 3 Phase, 50hz
Max. Bag width	150~430mm×2 lines
Producing length	300-650mm
Producing speed	100-380 pcs/min×2 lines
Film thickness	0.01-0.05mm
Main motor	1.8Kw Servo Motor
Main power	16Kw
Machine dimension (L×W×H)	6800×1700×1800mm

3. Macine Pictures

---
