| US$3,100.00-4,300.00 | 1 Set (MOQ) |
| Model | BWZ-B1 | BWZ-F | BWZ-F1 |
| Function | Automatic feeding,slotting and bending | Automatic feeding,slotting and bending | Automatic feeding,slotting and bending |
| Applicable Material Alu=Aluminum | Flat Alu,Folding Alu,Channelume | Flat Alu,Folding Alu | Flat Alu,Folding Alu |
| Material Width | Flat Alu:≤160mm Folding Alu:≤160mm Channelume:70,90,110mm | Flat Alu:≤150mm Folding Alu:≤108mm | Flat Alu:≤140mm Folding Alu:≤140mm |
| Material Thickness | Aluminum:0.3~1.5mm | Aluminum:0.3~1.2mm | Aluminum:0.3~1.0mm |
| Bending Radius | 7mm | 12mm | 12mm |
| Feeding | φ36mm feeding wheel+Guide material auxiliary+Encoder | φ30mm feeding wheel +Encoder | φ30mm feeding wheel +Encoder |
| Slotting System | Motor control | Air cylinder control | Motor control |
| Bending | Coupled extrusion-Double copper shaft flat arc bender | Coupled extrusion-general arc bender | Coupled extrusion-general arc bender |
| Control System | ADT | Leetro CBS4 | ADT |
| Power | <1500W | <1500W | <1500W |
| Air Pressure | 0.6MPa | 0.6MPa | 0.6MPa |
| File Format | Dxf, Ai,Plt | Dxf, Ai,Plt | Dxf, Ai,Plt |
| Working Voltage | 220V/ 50-60HZ/1P | 220V/ 50-60HZ/1P | 220V/ 50-60HZ/1P |
| Net Weight(kgs) | 320 | 240 | 250 |
| Overall Size(mm)(L*W*H) | 2100*800*1530 | 1350*700*1300 | 1340*680*1300 |
