| US$5,000.00-20,000.00 | 1 Piece (MOQ) |
| Vessel part | Parameter values | ||
| Operating pressure MPa | 0.241~0.251 | ||
| Design pressure MPa | 0.930 | ||
| Test pressure during manufacturing MPa | hydraulic | 1.45 | |
| pneumatic | - | ||
| Operating temperature, °С | -20 ~ 55 | ||
| Design wall temperature, °С | 324 | ||
| Min allowable wall temperature of vessel, that is under design pressure , °С | -52 | ||
| Operating medium | TEAL(PYROPHORIC) | ||
Operating medium data | Class of danger | 3 | |
| Explosiveness | Yes | ||
| Fire hazard | Yes | ||
| Corrosion/erosion allowance during assigned lifetime, mm | 0 | ||
| Capacity,m3 | 0,18 | ||
| Empty vessel weight, kg | 200 | ||
| Max. weight of fluid filled*, kg | - | ||
| Assigned or estimated lifetime, years | 25 | ||
| Number of load cycles for the assigned or estimated lifetime | Max 1000 | ||
| Group of vessel as per table 1 of GOST R 34347-2017 | 1 | ||
| Work medium group as per TR CU 032/2013 | 1 | ||
| Equipment category as per TR CU 032/2013 | 1 | ||
| - for vessels with liquefied gases | |||
| Vessel part name (shell, head, grid, pipes, jacket etc.) | Q-ty, pcs. | Dimensions, mm | Material | |||
| Diameter internal or external | Wall thickness | Length (height) | Grade | Standard or technical requirements* | ||
| Обечайка внутреннего сосуда Shell of the inner vessel | 1 | O.D406 | 5 | 1258 | TP304L | ASME SA312/SA312M-2023 |
| Днище Head | 2 | O.D406 | 6 (мин. 5) 6 (min. 5) | 50 | SA-240 Gr.304L | ASME SA-240M-2023 |
| Applicable in the Russian Federation and the states having voted for approval of the interstate standard as mentioned in the foreword. | ||||||
| Item name | Q-ty, pcs. | Dimensions (mm) or number as per specification | Material | |
| Grade | Standard or technical requirements* | |||
| Vent pipr | 1 | DN 8 SCH STD | SA-312 TP304L | ASME SA312/SA312M-2023 |
| Reinforcing pad | 1 | OD170 t=6 | SA-240 304L | ASME SA-240M-2023 |
| Pipe | 1 | DN 80 SCH80S L=97 | SA-312 TP304L | ASME SA312/SA312M-2023 |
| Flange | 1 | DN 80 ANSI 300# B=73.66 | SA-182 F304L | ASME B16.5-2020 |
| Flange | 1 | DN 40 ANSI 150# B=36.4 Y=165 | SA-182 F304L | ASME B16.5-2020 |
| Pipe | 1 | DN 100 SCH40S L=112 | SA-312 TP304L | ASME SA312/SA312M-2023 |
| Flange | 1 | DN 100 ANSI 300# B=102.26 | SA-182 F304L | ASME B16.5-2020 |
| Flange | 1 | DN 20 ANSI 300# B=19.5 Y=160 | SA-182 F304L | ASME B16.5-2020 |
| Flange | 1 | DN 20 ANSI 300# B=19.5 Y=132 | SA-182 F304L | ASME B16.5-2020 |
| Flange | 1 | DN 20 ANSI 300# B=19.5 Y=172 | SA-182 F304L | ASME B16.5-2020 |
| Base plate | 2 | t=16 | SA-240 Gr.304L | ASME SA-240M-2023 |
| Rib plate | 4 | t=16 | SA-240 Gr.304L | ASME SA-240M-2023 |
| Pad | 2 | t=5 | SA-240 Gr.304L | ASME SA-240M-2023 |
| Lifiting lug | 2 | t=18 | SA-240 Gr.304L | ASME SA-240M-2023 |
| Plate | 2 | t=10 | SA-240 Gr.304L | ASME SA-240M-2023 |
| Nsulation support ring | 2 | t=6 | SA-240 Gr.304L | ASME SA-240M-2023 |
| Applicable in the Russian Federation and the states having voted for approval of the interstate standard as mentioned in the foreword. | ||||
