Basic Info.
Machining Process
Hydraulic
Vibrating Amplitude
2.6mm
Product Description
Product Description
Portable Concrete Pump Diesel Engine 58m Concrete Mixer Pump HB58V With Remote Control
1.Ultimately Safe Boom.
2. Lower Structure of High Rigidity.
3.Hydraulic System of Outstanding Performance.
4.Effectively reduce emissions with the reversing, vulnerability of longer life.
5.The pumping system adopts electric control reversing, reversing faster and the system impact smaller.
6.The actual pumping efficiency is more than 5% higher than the conventional hydraulic control reversing system.
Detailed Photos
Product Parameters
Category
| Item
| Unit
| HB67V
|
Overall
| Outline dimension
| mm
| 15780*2500*4000
|
Overall weight
| kg
| 53000
|
Chassis
| Model
| -
| Actros 5046E5
|
Wheelbase
| mm
| 2020+5180+1350+1450
|
Max.power
| kW
| 335
|
Emission standard
| -
| China V
|
Pumping system
| Theoretical
| m³/h
| 170
|
Concrete pumping pressure
| MPa
| 8
|
Theoretical pumping times
| Times/min
| 21~23
|
Delivery cylinder diameter x stroke
| mm
| φ260×2000
|
Placing boom
| Reach height
| m
| 66.1
|
Reach depth
| m
| 48.6
|
Slewing radius
| m
| 60.9
|
Slewing angle
| °
| ±270
|
Others
| Transfer tuble
| -
| Rock valve
|
