| US$15,000.00 | 1 Piece (MOQ) |
| SPECIFICATION | MODELS | ||||
| C6251 1000,1500,2000,3000 | C6256 1000,1500,2000,3000 | C6256E( BIG HOLE 1000,1500,2000,3000 | |||
| CAPACITY | |||||
| Swing over red | 510mm(20") | 560mm(22") | 560mm(22") | ||
| Swing Over cross slide | 305mm(12") | 355mm(14") | 355mm(14") | ||
| Swing of gap | 735mm(28-7/8") | 785mm(30-7/8") | 785mm(30-7/8") | ||
| Length of gap | 170mm(6-11/16") | ||||
| Width of bed | 350mm(13-3/4") | ||||
| HEADSTOCK | |||||
| Spindle nose | D1-8 | ||||
| Spindle bore | 80mm(3-1/8") | 105mm(4-1/8") | |||
| Taper of spindle bore | No.7Morse | 113(1:20) | |||
| Range of spindle speed | 12changes25-2000r/min | 12changes 25-1500r/min | |||
| FEEDS AND THREADS | |||||
| of compound rest | 130mm(5-1/8") | ||||
| of cross slide | 316mm(12-15/16") | ||||
| Leadscrew pitch | 6mmOr4T.P.L | ||||
| Max.section of tool | 25×25mm(1×1") | ||||
| Longitudinal feeds range | 35kinds0.059-1.646mm/rev(0.0022"-0.0612"/rev) | ||||
| Cross feeds range | 35kinds0.020-0.573mm(0.00048"-0.01354") | ||||
| Metric threads range | 47kinds0.2-14mm | 41kinds 0.1-14mm | |||
| Inch threads range | 60kinds2-112T.P.L | ||||
| Diametrical pitches range | 50kinds4-112D.P. | ||||
| Module pitches range | 34kinds0.1-7M.P. | ||||
| TALLSTOCK | |||||
| Dia of tailstock sleeve | 75mm(3") | ||||
| Travel of tailstock sleeve | 180mm(7") | ||||
| Morse taper of tailstock sleeve | No.5Morse | ||||
| MOTOR | |||||
| Power of main motor | 7.5kw(10HP)3PH | ||||
| Power of coolant pump | 0.1kw(1/8HP),3PH | ||||
| DIMENSION AND WEIGHT | |||||
| Overall dimension(L×W×H)mm | 2390x1150x1430mm(1m) 2840x1150x1430mm(1.5m) 3340x1150x1430mm(2m) 4340x1150x1430mm(3m) | 2390x1150x1460mm(1m) 2840x1150x1460mm(1.5m) 3340x1150x1460mm(2m) 4340x1150x1460mm(3m) | |||
| Packing size(L×W×H)mm | 2450x1190x1740mm(1m) 2900x1190x1740mm(1.5m) 3400x1190x1740mm(2m) 4400x1190x1740mm(3m) | 2450x1190x1740mm(1m) 2900x1190x1740mm(1.5m) 3400x1190x1740mm(2m) 4400x1190x1740mm(3m) | |||
| Net weight | 2070kg(1m) 2160kg(1.5m) 2435kg(2m) 2805kg(3m) | 2195kg(1m) 2285kg(1.5m) 2560kg(2m) 2930kg(3m) | |||
| Gross weight | 2460kg(1m) 2550kg(1.5m) 2840kg(2m) 3270kg(3m) | 2600kg(1m) 2690kg(1.5m) 2980kg(2m) 3410kg(3m) | |||
| No | C6251 (Standard Accessories) | C6256(C6256E) (Standard Accessories) | Quantity |
| 1 | jaws self centering chuck Φ315MM | 3-jaws self centering chuck Φ315MM | 1 Pcs |
| 2 | 4-jaws independent Φ35 0MM 4 | 4-jaws independent Φ350MM 4 | 1 Pcs |
| 3 | Foot brake | Foot brake | 1 Set |
| 5 | Face Plate | Face Plate | 1 Pcs |
| 6 | Auto lubrication system | Auto lubrication system | 1 Pcs |
| 7 | Full length splash guard | Full length splash guard | 1 Pcs |
| 8 | Operational Manual,tool box , | Operational Manual,tool box , | 1 Pcs |
