Advanced PLC Multi-Blade Bridge Cutter for Stone and Marble

Product Description

Product Application
6 Pillars Multi-blade Stone Cutting Machine HLQY-32-1700 is a new developed heavy-duty stone machinery. Equiped with 6 pillars for spindle sliding and 32 pieces of circle blades, it's suitable for cutting granite blocks into slabs high efficiently.

TECHNICAL DATA FOR HLQY-32-1700
Configuration	Max. blade diameter	mm	Φ1700
	Power of main motor	kw	75 (6P)
	Power of pump motor	kw	5.5
	Power of stroke motor	kw	5.5
	Power of vertical motor	kw	3
	Gross Power	kw	104
	Length of cross-beam	mm	8400 / 9860
Main Performance Parameters	Cutting Length	mm	4000 / 5460
	Cutting Width	mm	2400
Measurement	Gross weight	kg	33000 / 35500
	Dimension (LxWxH)	cm	880(1025)x626x485

Main Features 1) Adopts 6 pillars for spindle sliding, which ensure the structure of the machine is steady and the lifting is stable.
2) Super large crossbeam that weighs 14.5t above is used, which make the machine run firm and stable.
3) Crossbeam and carling adopt Taiwan's Hiwin linear guide to move, which ensure high precision of cutting and long life.
4) Siemens electronic control system is equipped for good stability and high automation performance.
Detailed Images

Elevator Guide Rail
Adopts 6 big strong pilllars
as sliding guide for spindle, covered by fabric for preventing pollution.

Circle Blades
Original: China
32 pieces of blade can be hanged for high-efficient production.
Electronic Control System
Brand: SiemensOriginal: Germany Famous product, equipped for good stability and high automation performance.
Linear Guide
Brand: HiwinOriginal: Taiwan, ChinaFamous, top quality material is used on crossbeam and carling for good performance.

Our Service
Pre-Sales Service
* Inquiry and consulting support.
* Sample testing support.
* View our Factory.
After-Sales Service
* Training how to instal the machine, training how to use the machine.
* Engineers available to service machinery overseas.
