Product Details
Product Description
Product Description
Features:
1. The nameplate embossing machines is good precision of embossed characters,beautiful characters, the average failure-free time is three years;
2. The embossed character die of Nameplate embossing machines is made of mould steel, with a long life span of up to 12 months;
3. The software of Nameplate embossing machines is powerful and can be networked with the company’s internal LAN for direct production scheduling management; it can be networked with other computers for communication, accepting output instructions, printing associated data, etc.; it can also be connected with electronic scales to directly emboss important data on the sign;
4. The nameplate embossing machines feeding mechanism (industrial grade X-Y scanning system) infrastructure parts using precision mould casting, good overall processing performance, to ensure the high accuracy of the movement of the feeding mechanism;
5. Feeding mechanism movement vice using imported linear motion guide, self-lubrication, self-sealing dust proof, to ensure that the movement vice wear is very small, so that the sign embossing machine long time in high precision and stable operation;
6. Can provide automatic loading and unloading jig for the sign embossing machine;
7. The embossed characters of nameplate embossing machines are raised effect, with a three-dimensional sense, can be embossed two pieces of the same sign at a time.
Technical Data:
Machine Name
| Nameplate Embossing Imprinter Machine
|
Model
| PEYY-100
|
Machine Type
| Desktop
|
Size of Nameplate
| 120mm×80mm
|
Imprint Scope
| 120mm*65mm
|
Imprint Speed
| 2 Characters/Second
|
Imprint Content
| English Characters,Numbers,etc
|
Size of Character
| 3-4mm
|
Imprint Depth
| 0.2-1mm
|
Power Supply
| 220V±10％, 50HZ ±5％
|
Machine Power
| ≤500 W
|
Working Environment
| 0～40 ℃
|
>>
