Hot Sell Wiped Film Distillation for Essential Oil

Product Description

Product Description
Hot sell wiped film Distillation for essential oil
Wiped film Molecular Distillation / Short Path Distillation is a comparatively new separation technology. It can separate liquid-liquid mixture under temperature that is far lower than a boiling point by the difference of mean free path of molecules under high vacuum conditions. Such separation is difficult or unable to achieve normal distillation equipment. Molecular Distillation is especially suitable to separate substances of high boiling point, heat sensitive, and easy to be oxidized.
Product Parameters

Model	MDS-10CE short path distillation units
Material tank	Upgrade15L jacketed stainless steel tank
	2 sight glass at the top, with insulated ball valve.
Material charging	Gear pump
	Flow 3L~15L/H
	200W motor, electronic speed regulation.
Evaporator	Evaporation area 0.1m2
	Film-forming way: scraper (roller is optional)
	Material:316L
	Mechanical seal (Magnetic seal is optional)
	Film-forming motor: 370W, mechanical constantly variable transmission, 200~1000rpm/min
Cold trap	1. 0.4m2 chiller cooling cold trap
	2. 3L liquid nitrogen cold trap
	3. Dual-purpose(chiller & liquid nitrogen cold trap dual purpose)
	Choose 1 of the above 3 types
Heavier component discharge	Gear pump
	Flow 3L~15L/H
	200W motor, electronic speed regulation.
Lighter component discharge	Gear pump
	Flow 3L~15L/H
	200W motor, electronic speed regulation.
Material pipeline	Jacketed insulation
Shelf & assemble	304 stainless steel pipe

Our Advantages
Certifications
Packaging & Shipping
Company Profile
FAQ
1.Q:Are you trading company or manufacturer?
We are professional manufacture of lab equipment and we have our own factory. And welcome to visit our factory.
2.Q:What's the processing capacity do you have?
We can offer you 1~3L/H, 5~12L/H, 10~25L/H, 18-30L/H, 20~60L/H.
3.Q: Can you do OEM service ?
A: We can provide the specific products needed around the world at significantly lower costs.
TOPTION also offers a Private Labeling Program to provide high quality lab supplies at lower prices.
If you need further information regarding our OEM or Private Label programs, please contact us freely.
4.Q: How long is your delivery time?
A: Usually, delivery time is 30-45 days after receiving your payment.
5.Q: How about your quality warranty ?
A: Normally all TOPTION products are supplied with a warranty of 12 Months from the date of shipment.
6. Q:Can we visit your factory?
A: Welcome visit our factory.
7. Q:If we want to customize molecular distillation , is it available?
Sure,we are experienced at this,we have professional technical team, we can design the drawing according to your requirements and then produce it.

---
