Plastic Pet Bottle Recycling Line

Product Description

Specifications

PET waste bottle recycling line
High automation
Perfect synchronized
Customized process solutions

Overview

To separate PET bottles to flakes from PE/ PP label, cap, oil, garbage, protect the environment, avoid white pollution.

Recycled PET can be used again to produce PET-based plastic products, e.g. bottles (not food & beverage-grade), fiber/cloth, sheet, strap band and, etc.

Range Available:

Input capacity	500kg/h	1000 kg/h	2000 kg/h
Workshop(M*M*M)	42 (L)×10(W)×6(H)	55(L)×15(W)×6(H)	70(L)×18(W)×6(H)
Manpower	6 Persons	8 Persons	12 Persons
Installation power	156KW	307KW	420KW
Water Consumption:	2 Ton/h	3.5 Ton/h	5 Ton/h

Features:
The whole line is fully automatic and it has characteristics of high efficiency, low noise and easy operation.
The line can easily wash and recycle waste PET bottle flakes ,which includes PE/PP labels, PVC labels, paper labels, HDPE cups, glue, mud, beverage leftover, oil, and scrap iron.
It adopts hot water washing to get good quality. Various output capacities can be chosen: 500kg/h, 1000kg/h, and 2000kg/h(Customized).
The degree of cleaning is as much as 96% and the degree of drying is as much as 98%.

Main List And Function:

No.	Item	Qty	Remark
1	Bale Breaker	1 Set	Cut And Break Packaged PET Bottles
2	Belt Conveyor	1 Set	Conveying Bottles
3	Screening Machine	1set	Filtering Sand, Dirty, Impurity
4	Belt Conveyor	1set	Conveying Bottles
5	Label Remover	1 Set	Removing Label From Surface Of Bottle Label Removing Efficiency: 90%-95%
6	Manual Sorting Table	1 Set	Sorting Different Plastics By Manually
7	Metal Detector	1set	Detecting Metal, Aluminum, Stainless Steel And So On Automatically
8	Belt Conveyer	1 Set	Conveying Bottles
9	Wet Crusher	1 Set	With Water, The Material Of The Blade Adopt Skd-Ii Or 9crsi
10	Screw Feeder	1 Set	Conveying Flakes
11	Twin Screw Floating Washer	1 Set	Washing And Separate PP Caps/Label According To Different Specific Gravity
12	Screw Feeder	1 Set	Conveying Flakes
13	Hot Steam Washer	1 Set	Removing Oil By NAOH And Hot Washer Or Hot Steam
14	Screw Feeder	1 Set	Conveying Flakes
15	Friction Washer	1 Set	High Friction Efficiency By High Speed, Adopt Germany Technology
16	Twin Screw Floating Washer	1 Set	Washing And Separate PP Caps/Label According To Different Specific Gravity
17	Dewatering Machine	1 Set	High Dewatering Efficiency By High Speed, Adopt Germany Technology, Water Content 5%
18	Label Separator	1set	Separating Leftover Label From Pet Flakes
19	Drying System And Storage Hopper	1 Set	Drying By Electric, Water Content ≤2%
20	Electrical Control Cabinet	1 Set	Adopts ABB , SIEMENS And OMRON As Main Electric Component.

---
