Hitachi Zx210W 20t Wheeled Excavator

Product Description

Dimensions Boom/Stick Option (Mex) 1A Shipping Length Of Unit - 9790mm
C Shipping Height Of Unit - 3160mm
I Max Cutting Height - 9420mm
J Max Loading Height - 6640mm
K Max Reach Along Ground - 9270mm
L Max Vertical Wall Dig Depth - 4890mm
M Max Digging Depth - 5730mm Boom/Stick Option (Mex) 2A Shipping Length Of Unit - 9810mm
C Shipping Height Of Unit - 3110mm
I Max Cutting Height - 9850mm
J Max Loading Height - 7040mm
K Max Reach Along Ground - 9950mm
L Max Vertical Wall Dig Depth - 5800mm
M Max Digging Depth - 6420mm Dimensions
D Wheelbase - 2750mm
H Tail Swing Radius - 2700mm
B Overall Width - 2500mm
E Ground Clearance - 340mm
F Overall Width - Outriggers Down - 3700mm
G Height To Top Of Cab - 3110mm
N Upper Structure Clearance - 1275mm
Specifications Engine Number Of Cylinders - 6 Engine Make - 2353 Engine Model - 6BG1XABFA Net Power - 109.7kw Power Measured @ - 2100rpm Displacement - 6.5L Torque Measured @ - 1600rpm Net Torque - 550Nm Aspiration - turbocharged, intercooled Operational Operating Weight - 20600kg Fuel Capacity - 340L Cooling System Fluid Capacity - 23L Engine Oil Capacity - 25L Front Diff Fluid Capacity - 11L Rear Diff Fluid Capacity - 13L Hydraulic System Fluid Capacity - 310L Operational Voltage - 24V Hydraulic System Relief Valve Pressure - 34335.9kPa Hydraulic Pump Type - 2 variable displacement axial piston pumps Hydraulic Pump Flow Capacity - 428L/min Oscillating Axle Angle - 12degrees Swing Mechanism
Swing Speed - 13.6rpm Transmission Transmission Type - 2 gear powershift Number Of Forward Gears - 2 Number Of Reverse Gears - 2 Max Travel Speed - 25km/h

---
