2" High Pressure Diesel Pump, High Efficient

US$170.00 10 Pieces (MOQ)

Basic Info.

Model NO.

DP20H, DP30H, DP40H

Pressure Medium

Water

Type

Handheld

Position of Pump Shaft

Vertical Edge

Certification

Dp20h-C

2"Iron Cast Diesel High Pressure Pump

Dp30h-C

3"Iron Cast Diesel High Pressure Pump

Sp20d,Sp30d,Sp40d

2′3′4′ Clean Aluminum Water Pump

Dp40h-C

4" Iron Cast High Fire Fighting Pump

Dp20h,Dp30h,Dp40

2"3"4" Aluminum High Pressure Pump

Transport Package

by carton

Specification

diesel high pressure pump 2" 3"

Trademark

hot-stuff

Origin

fujian

HS Code

8413781009

Production Capacity

3000pcs/month

Product Description

Diesel water pump powered by 4-stroke diesel engine. High output trash pumps capable of handling grancile up to 1.5" diameter, removable front cover ofr easy clearing and maintenance, highly effective mechanical seal compact in structure and light in weight, aluminum alloy high presure easily.

model no:	DP20H	DP30H
pump type:	centrifugal pump/self-priming
Self-priming time(s/4m)	60	65
engine type:	single-cylinder vertical direct injection 4-stroke air cooled diesel
powered by diesel engine:	5HP	9HP
Heavy-duty fuel frame protection
suction and discarge port:	2"	3"
engine speed:	3600rpm
max displacement:	30m3/h	40m3/h
lift H max:	55m	70m
max suction head(m):	7m	8m
engine model:	178F	186F
engine bore xstroke	78x62mm	86x70mm
engine displacement:	296ml	296ml
start model:	manual or electrical start
fuel tank capacity:	3.5L	5.5L
cooling system:	forced air
lub oil capacity:	1.1L	1.65L
connector of infall or outfall:	yes
seal ring:	yes
hoop:	yes
size:	590x475x540	660x490x610
qty/20ft container	144pcs	96pcs
