25 Kw Three-Phase Permanent Magnet Synchronous Motor Electric Car Conversion Kit Adjustable Speed

Product Description

Product Description This product is based on customer needs and is specially upgraded for the van and small truck market. It has the characteristics of high safety, small size, lightweight, high power density, high efficiency, and high reliability.
Product Parameters

TZ180XS Series Motor Specification
Motor Model	Rated Power(kW)	Peak Power (kW)	Rated Torque(N.m)	Peak Torque (N.m)	Rated Speed(rpm)	Peak Speed (rpm)	Voltage (V)	Current (A)	Protection Level	Cooling Method
TZ180XS-10-03	10	15	48	125	/	5200	DC384V	/	IP67/H	Liquid Cooling
TZ180XS-20-01	20	40	63.7	130	/	8000	DC365V	/	IP67/H	Liquid Cooling
TZ180XS-25-01	25	50	50	130	/	7500	DC144V	/	IP67/H	Liquid Cooling
TZ180XS-30-02	30	60	90	220	/	9000	DC336V	/	IP67/H	Liquid Cooling
TZ180XS-40-04	40	80	110	300	3500	10000	/	/	IP67/H	Liquid Cooling

Detailed Photos Our Advantages 1, Comes with ASR (drive anti-skid control) to improve the safety of the whole vehicle;2, The power is stronger, the peak torque of the motor ≥223N.m, and the wheel side ≥2340N.m;3,Small size and lightweight (5kg, 21.5kW / kg);4, High EMC level(Class 4)5, The highest efficiency of the system reaches 95%;6, With a comprehensive active security strategy function. (Active anti-shake, anti-slope, limp, glide feedback, etc.)
Company Profile
FAQ Q1. What are your terms of packing?
A: Generally, we pack our goods in neutral white boxes and paper cartons. If you have a legally registered brand, we can pack the goods in your branded boxes after getting your authorization letters.
Q2. What are your terms of payment?
A: T/T 50% as deposit, and 50% before delivery. We'll send you the photos of the products and packages before you pay the balance. For big orders, we accept L/C at sight.
Q3. What are your terms of delivery?
A: EXW, FOB, CFR
Q4. How about your delivery time?
A: Generally, it will take 15 to 45days after receiving your advance payment. The specific delivery time depends on the items and the quantity of your order.
Q5. Can you produce according to the samples?
A: Yes, we can produce your samples or technical drawings. We can produce the molds and fixtures in-house.
Q6. What is your sample policy?
A: We can supply the sample if we have the parts in stock, customers have to pay the sample cost and the courier cost.
Q7. Do you test all your goods before delivery?
A: Yes, we have a 100% test before delivery, if necessary we can send an inspection report before delivery.
Q8: How do you make our business long-term and good relationship?

---
