Angle Drilling Machine FINCM Tower Structure Fabrication CNC Hydraulic Angle Automatic Punching Shearing Marking Machine

Product Description

Product Description
APM0908 FINCM Tower Structure Fabrication CNC Hydraulic Angle Automatic Punching Shearing Marking Machine 40mm*40mm*3mm-90mm*90mm*8mm
It is mainly used for customers to manufacture angle steel components, complete typing, punching, fixed length cutting on angle steel. Simple operation, high production efficiency.

Technical specification of APM0908

Model	APM0908
Angle Size (mm)	40x40x3~90x90x8(Q345)
Max. workpiece length (m)	12
Max. punching capacity(DxT mm)	Φ25.5mm x8mm
Nominal punching force (kN)	350
Nominal marking force (kN)	1030
Nominal cutting force (kN)	1000
No. of character group (piece)	4
No. of character in each character group (piece)	18
Character size (mm)	14x10x19
Range of stadia (mm)	20~170 (stepless)
No. of punch on each side (piece)	3
Max. feeding speed (m/min)	40
No. of CNC axes (piece)	3
Overall size (m)	25x7x2.2
Total power (kW)	31.4
Machine weight (kg)	Approx. 15000

Angle feeding Speed: 40m/min, the effiency is about 1000 holes/hour
The finished angle conveyor is rotated to one side by pneumatic power. The max. Length of finished angle is 8 m.
There are four transverse conveyors which can infeed automatically.
Type of programming: Keyboard input, USB interface input, floppy disc input.
Working environment:
Working temperature: 0~ 40 degree
Power: Three phase four wire system
AC Voltage: 380V
Fluctuation of voltage: ± 10%
Frequency: 50 Hz
Main outsourcing components list of APM0908:

No	Name	Brand	Manufacture
1	AC servo motor	Delta	Taiwan China
2	PLC	Delta	Taiwan China
3	Electromagnetic valve	Atos/Yuken	Italy/Tawan
4	Relief valve	Atos/Yuken	Italy/Tawan
5	Double vane pump	Albert	USA
6	Air valve	SMC/Airtac	Japan/Taiwan China
7	cylinder	SMC	Japan

Relateed Products
Company Profile
Shandong FIN C N C MACHINE CO., LTD is located in Jinan high tech Development Zone, is committed to the development, research, design, manufacture, sales of CNC machine tools, such as processing angle bar, beam channel profiles, steel plates, tubesheet and flanges. It is mainly used in iron tower, steel structure, heat exchanger, boiler, bridge, truck and other industries.FIN CNC machines exported to 50+ countries across globe market. Our company has strong R & D center with 30 engineers team, they have 20 years of experience ; 280 staff, plant area about 270,000 sqm. Main products: CNC Angle Line, CNC Beam Drilling Sawing Machine, CNC Plate Drilling Machine, CNC Rail Processing Machine, CNC Tubesheet Flange Drilling Machine, Truck beam plate punching machine. The company drafted many China national standards for C N C angle line
Cooperatine Supplier
Product Process Control
Sales Network
Our Service

1. 1. Do you provide machine operation training?
Yes. We can send professional engineers to the working site for machine's in- stallation,commissioning and operation training.
2. how can we guarantee quality?
Always a pre-production sample before mass production;
Always final Inspection before shipment;
3.What can you do if my machines have problems?
1) We can send you free components if machines are in warranty period;
2) 24 hours service on line;
3) We can assign our engineers to serve you if you want.
4.When can you arrange shipment?
For machines availablein stockthe shipment can be arranged within 15 days
after getting advance payment or L/C;For machines non available in stock, the shipment can be arranged with 60 days after getting advance payment or L/C.
5.what can you buy from us?
CNC Angle Line/CNC Beam Drilling Sawing Machine/CNC Plate Drilling Machine,CNC Plate Punching Machine Please share us your material size and your processing request, then we will recommend our machine most suitable and most cost effective for your work demand.
6. what services can we provide?
Accepted Delivery Terms: FOB,CFR,CIF,EXW,FAS,CIP,FCA,CPT,DEQ,DDP,DDU,Express Delivery,DAF,DES;
Accepted Payment Currency:USD,EUR,JPY,HKD,CNY;
Accepted Payment Type: T/T,L/C;
Language Spoken:English,Chinese

---
