| Model: | DL1 |
| | |
| Standard Deviation For 1Km Double Run Levelling |
| Digital Survey | 0.7mm |
| Optical Survey | 1.2mm |
| System |
| Working Range | 3M - 120M |
| Optical Minimum Focusing Range | 0.5M |
| Digital Minimum Focusing Range | 3M |
| Single measurement speed | < 3 sec |
| Bubble | 8'/2mm |
| Display |
| Minimum resolution (Ht) | 1mm/0.1 mm |
| Minimum resolution (Dist) | 1m |
| Telescope |
| Magnification | 32X |
| Objective Aperture | 38mm |
| Compensator |
| Type | Magnetic |
| Compensating Range | ±15' |
| Setting Accuracy | ±0.3" |
| Environmental conditions |
| Operating Temperature | -20°C to +50°C |
| Protection to dust and water | IP65 |
| Battery |
| AA dry cells (4XLR6 / AA 1.5V) | 20 hours continuous measurement |
| Weight |
| Net Weight including battery | 1.8KG |
Varies color options:(below color is regular stock, you could offer panton color with OEM MOQ)
