Numerical Control Double Column Gantry Round Table Surface Grinder with Horizontal and Vertical Shaft

Product Description

CNC Double Column Gantry Round Table Surface Grinder with Vertical and Horizontal Shaft
VSGK-1250
Performance and Feature
1. The numerical control vertical and horizontal double shaft round table surface grinding machine is special product developed by our company through absorbing domenstic and international advanced grinding machine structure technology.
2. General layout of the machine is workbench regularly rotates on the round guide of body, double upright column crossbeam, carriage is longitudinally reciprocated on the crossbeam, double grinding head structure,grinding head is vertically moved along the carriage, steady and compact overall strucyure, high precision, reliable performance, good manufacturability, convenient operation and use.
3. Horizontal grinding head adopts edge grinding of grinding wheel, upper and lower plane and inside hole, and can grinding the taper hole through insertion. The product is applicable to grinding of annular parts(such as value plates, saw blades and seal rings), and can grinding the simple annular curve surface on the end face.
4. The casting adopts resin sand casting process, good meterical(Ht250), high strength, is processed after manual aging treatment, precision is stable.
5. The machine adopts gantry structural form; the workbench adopts round static pressure guide, stable running and good shock absorption.
6. Crossbeam and carriage are installed in the upright column, carriage is installed in the crossbea, and grinding head and vertical slide carriage are installed in the carriage. Grinding wheel dresser is placed on the workbench, can be automatically trimmed through programming,also can be manually trimmed through electronic handwheel, the whole trimming process is convenient and quantitatively.
7. Grinding head is divided into vertical grinding head and horizontal grinding head,vertical grinding head can be moved 45°to the maximum.
8. Automatic lubricating pump automatically injects oil into lubrication parts regularly and quantitatively.
9. Machine tool cooling is independent water tank, supplies water through water pump, equips with magnetic separator for separating from scrap iron, and makes coolant clean and durable
10. Hydraulic parts of machine tool adopts independent oil tank, passea through oil filter, oil pump, pressure valve and distributor, supplies static pressure guide, oil supply system is equipped with pressure relay, oil pump is not started, pressure relay is not acted, workbench can be started uo, effectively guarantee the guide safety.
11. Safety protection part of machine tool adopts interlocking of electromagnetic chuck power, grinding head can't be turned on, effectively guarantee the personal safety of operator, avoid accidents caused by loss of excitation or misoperation of chuck.

Technical Parameter

Specifications	Unit	VSGK-2000
Diameter of workbench	mm	Φ2000
Maximum size of grinding workpiece(diameter x height)	mm	Φ2000x500
Maximum weight of grinding workpiece	kg	3000
Rotational speed of workbench (Variable frequency speed regulation)	rpm	3-35
Rotational speed of grinding head spindle	rpm	1000
Vertical movement speed of grinding head	mm/min	5-200
Vertical mocro-feed of grinding head	mm	5-500
Transverse horizontal movement speed of grinding head and carriage	mm/min	0.001
Rotation angle of vertical grinding head	°	0-45°
Total power of machine tool	kw	30
Weight of machine tool	T	27
Outline dimension of machine tool (length*width*height)	mm	4800x3900x3950
Maximum dimension of machine tool occupied space (length*width*height)	mm	5800x4900x3950

Our Advantages
1. Free replacing parts available in the warranty period. Cost price replacing parts available beyond the warranty period.
2. Quick action and reply for the technical questions at any time in the whole life of the machine.
3. Overseas after service center available in some region.
4. Engineer overseas service available on the requirement of customer(relative cost born by customer).
Packaging & Shipping
Company Profile
Timeway Machine Tool Co., Ltd. is a professional machine tool manufacturing enterprises, the main products include lathe, milling machine, grinding machine, etc., and according to customer needs we also can design and manufacture various special purpose machines, to provide relative technology upgrading and transformation services in machine tool field.
Since the establishment of the Ministry of Foreign Trade, we have participated in various domestic and international exhibitions such as the Autumn Canton Fair, Beijing Exhibition, Shanghai Exhibition, Moscow, Ethiopia, and Russia, and have maintained long-term friendly cooperative relations with exhibition customers.
Customer visited
So far, we have received many customers from abroad, and they are all very satisfied with our company and products
The following is one of the most satisfactory products recommended by customers, as well as our main product categories. you can click and view

Conventional Lathe	CNC Lathe	CNC Machining Center	CNC Milling Machine
Grinding Machine	Milling Machine	Special Use Lathe	Boring Machine

FAQ
Q: Why choose TIMEWAY MACHINE?
A: 1 . High quality with competitive price;
2 . Professional R&D team and 25 years export experience;
3 . Exported more than 60 countries;
4 . CE, ISO Certificates;
5 . 24 HOURS ONLINE SERVICE (SKYPE, WhatsApp, Wechat, Trademanager);
6 . 12 months quality warranty;
7 . Oversea engineers available for problem resolving;
Q: Do you have QC or any safety standards for your machinery?
A: yes, we have established a highly strict quality control department to guanrantee good quality.
Q: What's the MOQ?
A: 1 set (Only some low cost machines will be more than 1 set )
Q: What about the payment terms?
A: (1) T/T with 30% advanced payment, and 70% balance payment to be paid before shipment;
(2) Irrevocable LC at sight;
(3) Western Union, MoneyGram, etc.
Q: How about the warranty?
A: Warranty Period is one year after delivery. Even beyond the period, we will supply lifetime service for machine.

---
