Al2503 Bottom Loading Arm

Product Description

Product Description
The structure of AL2503 land loading arm:
Our loading arm in the workshop:
The general introductio for land loading arm:
Our land loading arm is especially designed for transporting fluid between piping system and tanker, which shall be designed for different tanker, liquids and site conditions.
Equipped with loading platform, folding stairs and safety cage to make the land loading arm into a complete loading system.
By level location or quantitative monitoring, while fluid level exceed the present value, provide the sound and visual alarm or the remote signal.
According to the products, models and requirements of customers, the operating modes could be manual, pneumatic or hydraulic etc.
The basic technical data for AL2503 land loading arm:

AL2503 is a typical of bottom loading arms.The type of loading arm usually connects to the tanker by flanges or quick coupling. It has good sealing performance.
Places Applied	Bottom closed loading or unloading
Applications	Product oil, chemicals, etc.
Nominal Diameter	DN50~DN100
Working Temperature	-196~250ºC
Working Pressure	PN1.0~PN4.0
Material of pipeline	Carbon steel, stainless steel, aluminum, low-temperature steel, PTFE lined etc.

Overseas project cases:

---
