X Ray Monoblock for Dental X Ray Unit

Product Description

Product Description
1. Power Supply: Lithium Ion Battery 2200mAh/14.8V
2. Output Electric Power: a. Maximum Tube Voltage:60KV±10% b. Maximum Tube Current:2mA±20% c. Frequency:30KHz d. Loading time:0.1S-4S,Allowable deviation±10%3. Tube parameters
a. Maximum Tube Voltage: 70KV
b. Focal spot: 0.4
c. Maximum tube current: 5mA


Competitive Advantage:
copper shell without any leadkage risk
small size
support customize or OEM
Application:
Our x-ray tubehead can be used on portable dental X-ray equipment.For more type of our x-ray tube, please see the following chart:

BRIEF SPEC.OF STATIONARY ANODE X-RAY TUBE
Type	Equivalent	Nominal Focal Spot Value	Max Rating(W)	Max. Voltag(kV)	Max Filament Current(A)	Target Angle ( °)	Anode Heat Content(KJ)	Anode Cooling Rate(W)	Dimension
									Length×Diameter
KL1-0.8-70	CEI OX/70-P	0.8	840	70	2.2	19	7	140	80×30
KL5-0.5-105	CEI OPX/105	0.5	1150(0.1s DC)	105	4	5	30	250	140×42
KL10-0.6/1.8-110	CEI OX110-15	0.6/1.8	880/5200(0.1s DC)	110	3.5/3.5	15	30	250	155×50
KL11-0.4-70	TOSHIBA D-041	0.4	430	70	3	12	4.5	110	67×30
KL20-2.8-105	CEI OX105-6	2.8	6000(0.1s AC)	105	5	19	30	250	145×45
KL21-0.7-70		0.7	N/A	70	3	16	7	210	67×30
KL22-1.8-90	CEI OX90-2	1.8	2200(0.1s AC)	90	4.3	19	25	250	140×42
KL25-0.6/1.5-110	CEI OX110-5	0.6/1.5	800/4000(0.1s DC)	110	4/4.5	12	30	230	135×50
KL27-0.8-70	CEI OX/70-M	0.8	840	70	2.2	19	7	140	72×30
KL32-0.5-80	BRAND X-RAY BX-1	0.5	N/A	95	2.4	12	16	160	125×35
KL54-0.5-100	TOSHIBA D-054	0.5	840/1750(1s,DC)	100	3.5	5	35	250	132×45
XD2-1.4/85		1.5	1400	85	2.5	23	10.2	225	110×35
XD3-3.5/100		2.6	3500	100	4.5	19	35	350	180×50
XD3A-3.5/105X	CEI OX105-4	2.6	3500	105	4.5	19	30	350	175×50
XC65		0.8	600	200	3±0.2	25			195×68
CX6828		0.8	200	160	3.5	25			195×68
CX6838		0.8	320	160	3.5	25			195×68
CX6858		0.8	500	160	3.7	25			195×68

Hot Sales Products
Company Profile
Packaging & Shipping
FAQ1. Are you manufacturer?Yes, we are a professsional manufacturer of x-ray machine in China.Stable quality and foremost service always be the key that we focus on.2. How long is your lead time?Normally it's about 30-40days after order confirmed.3.How about the warranty and services?Provide one year warranty and lifetime technic support.Accept to send our engineer to your country for training in additional cost.Free training one-on-one in our factory for free.4. How long is the guarantee period of the machines? When does it start?The guarantee period of our equipment is one year, calculated the date from when it's installed. During the guarantee period, we provide normal damaged spare parts for free. After the guarantee period, we only take the cost of components.

---
