Plastic to Fuel Oil Pyrolysis Machine 30t Continuous Waste Tyre Recycling Plant

Product Description

Company Profile
Our Qingdao Longyuan Baihong Machinery Equipment Co., Ltd is a big manufacturer for Pyrolysis
Equipment for 22 years in China. We located at Qingdao-----a beautiful and Industry developed city.We
established in year 1997, our main products are environment pyroloysis equipment.The company has
passed ISO9001 certification, CE certification and SGS international third party certification.To the
overall design, production and manufacturing, installation and commissioning, technical training, after
-sales service in the whole industrial chain operation of high-tech enterprises.
Product details
1. The pyrolysis furnace adopts the structure of heat storage body to fully recycle waste heat, which can
not only extend the service life of the main furnace, but also save fuel.Thus further saving productioncosts.
2. the furnace adopts special high temperature resistant boiler steel, service life up to 8 years.
3. The equipment is equipped with infrared blocking prevention and warning dredging device, which can
give early warning of pipe blockage in the production process and automatically solve the blockage
problem, so as to ensure that the main furnace will not have safety problems due to pipe blockage in the
production process.
4. The slag discharging system adopts a dual-cycle structure to control the slag discharging time at about
30 minutes.Slag quickly clean.
5. Adopt a new waste gas purification system to make the gas discharged after purification meet the
relevant national emission standards.
6. Excess combustible gas is dehydrated, sulfur removed and impurities removed in the purification system,
and then compressed by the special gas compressor and stored in the gas storage tank. It can be used for
heating later, or supplied to the gas generator for use or sale.
7. Convection vents and rapid cooling devices are added in the main furnace to reduce the temperature of
the main furnace to below 100 degrees within one hour.

No	Specification	Batch type waste tyre/plastic/rubber pyrolysis plant
1	Model	BH-B5	BH-B8	BH-B10	BH-B12
2	Working way	Batch type	Batch type	Batch type	Batch type
3	Raw material	Waste tyre,waste plastic,waste rubber
4	24 hour handling capacity	5T	8T	10T	12T
5	24 hour oil production	2.4T	4T	4.4T	4.8T
6	Heating way	Directly heating	Directly heating	Directly heating	Directly heating
7	Working pressure	Ordinary pressure	Ordinary pressure	Ordinary pressure	Ordinary pressure
8	Cooling way	Water cooling	Water cooling	Water cooling	Water cooling
9	Water consumption	4T/H	6T/H	7T/H	8T/H
10	Nosie	≤85DB(A)	≤85DB(A)	≤85DB(A)	≤85DB(A)
11	Total weight	20T	26T	27T	28T
12	Area( coiled tube type)	20*10*5M	20*10*5M	22*10*5M	25*15*5.5M
13	Area(tank type)	27*15*5M	27*15*5M	29*15*5M	30*15*5.5M

1.The Raw Material For Pyrolysis Machine
2.End product percentage and useage

NO.	Name	Percentage	Usage
1	Tyre oil	45%	* can be sold directly. * make diesel and gasoline by use oil distillation machine. * can be as fuel.
2	Carbon black	30%	* can be sold directly. * make fine carbon by use carbon black refining machine. * make pellet by use carbon make pellet machine.
3	Steel wire	15%	* can be sold directly. * make steel bloom by use hydraulic press-packing
4	Oil gas	10%	* can be as fuel burn by use gas burn system (pyrolysis machine included) *extra gas also be storage as fuel for other heating.

3.The available fuel for pyrolysis processing

NO.	Fuel
1	Oil(fuel oil, tyre oil, heavy oil etc..)
2	Natural gas
3	Coal
4	Firewood
5	Carbon black pellet

Details Images
Our Advantages
1. Security:
a. Adopting automatic submerged-arc welding technology
b. All of the welding will be detected by the ultrasonic nondestructive testing method to ensure the welding
quality and the welding shape.
c. Adopting manufacture process controlling system on the quality, every manufacture process, manufacture
date, etc.
d.Equipped with anti-explosion device, safety valves, emergency valves, pressure and temperature meters,
as well as the alarming system.
2. Environmental-friendly:
a. Emission Standard: Adopting special gas scrubbers to remove acid gas and dust from smoke
b.Smell during operation: Fully enclosed during the operation
c.Water pollution: No pollution at all.
d. Solid pollution: the solid after pyrolysis is the crude carbon black and steel wires which can be
deep-processed or sold directly with its value.
workshop
Why Choose Us
Our service
1.Quality warranty period: One year warranty for the main reactor
of pyrolysis machines and lifetime maintenance for complete set of machines.
2.Our company sends engineers for installation and commissioning in buyer's site including
the training of skills of buyer's workers on operation, maintenance, etc.
3. Supply layout according to buyer's workshop and land, civil works information, operation
manuals, etc. to the buyer.
4. For the damage caused by the users, our company provides the parts and accessories
with cost price.
5. Our factory supplies the wearing parts with the cost price to clients.

---
