Tianjin Leather Hole Punching Machine in 900X600mm

Product Description

Product Description Main Features:
Multi-type punching knife for easy exchange, catering to individual needs.
New gantry structure for fast punching speed and silent operation.
Mechanical punching preserves original color and quality of leather.
Equipped with casters for easy machine mobility.
Customized special electronic control compatible with other machines.
Industrial vacuum silent cleaner for effortless removal of leather scraps.
Company Name: Tianjin Meifurui Technology Co., Ltd.
Punching Machine Technical Description
Tianjin Meifurui Technology Co., Ltd. - Punching Machine Maximum Punching Speed: 1200 holes/min
Punching Tools: 5 types available (0.8mm, 1.0mm, 1.2mm, 1.5mm, 2.0mm round hole)
Customization: Can install other customized tool heads
Pattern Reading Mode: U disk
Drive Motor: Servo motor
Power Supply: Three-phase 380V/50Hz or single-phase 220V
Drawing Format: DXF
Additional Features: Brush function for manual sewing, customizable processing area (e.g., 1000-2000mm)
Efficiency Enhancements: Customizable number of heads (e.g., 8 punching heads), film feed device option for improved efficiency
Punching Programming: Provides hundreds of punching programming data

	product name	specifications and models	remarks
1	Single head CNC punch	MFR-P-1.5-900*600	1 piece at a time
2	Double head CNC punch	MFR-P-2.5-900*600	2 piece at a time
3	Single head CNC punch	MFR-P-1.5-1200*800	1 piece at a time
4	Double head CNC punch	MFR-P-2.5-1200*800	2 piece at a time
5	Four head CNC punchi	MFR-P-4.5-900*600	4 piece at a time
6	Six head CNC punch	MFR-P-6.5-900*600	6 piece at a time

---
