Pulverizer Grinder for PP HDPE LDPE PVC Waste Recycling Machine

Product Description

Product Parameters

Mode	SHXR-650	SHXR-1000	SHXR-1280
Pulverizing chamber diameter	φ650 mm	φ1000 mm	φ1280mm
Number of rotors	one group
Spindle speed(rpm)	3200	3500	3700
Type of cooling	water cooling
Main motor power (kw)	22/30/37/45/55	30/37/45/55	37/45/55
Output (kg/h)	500-1200	500-1500	1000-2000
Fineness	5-100 mesh
Weight (kg)	1000	1100	1500
Size(mm)	650*450	1000*450	1280*450

Technical Features

Plastic milling machines are widely used in chemical, waste recycling, plastic pipe profile manufacturing, plastic modification and other fields of various plastic materials. Classified according to the principle of milling, the abrasive machine's main rotor (turbine) milling machine and grinding disc milling machine

1. Using water circulation and wind cooling, suitable for thermoplastic material processing.

2. Easy installation and maintenance, open the cover of the grinding room can be cleaned.

3. The high-speed rotation of the spindle grinding disc produces high-speed rotating air flow (local eddy current), which makes the incoming material move with the grinding disc and the cutter head have a strong collision and cutting into powder.

4. The grinding disc and cutter blade are professionally designed, made of SKD11 material and high-density wear-resistant steel casting process, and have good wear resistance after heat treatment and vacuum quenching.

5. The machine is compact in structure, small in size, only need to open the door cover to maintain and maintain, fully sealed, no dust missing.

6. It is equipped with air feeding and discharging device to ensure uniform material cooling and fast cooling speed.

7. Equipped with a feeding machine, control the amount of material feeding, dust removal device to reduce dust.

8. Beautiful design, bag type dust collector, dust collector two in one, can also be equipped with pulse dust collector, belongs to the environmental protection type of high-quality products, more easy to replace the wearing parts in the machine compared with similar products, easy to save time 2 hours, safe and reliable.

9. The feed port can be equipped with a magnetic device to absorb the iron filings in the raw material to prevent entering the grinding chamber and damaging the tool

Application Areas
Company Profile
Wuxi Songhu Xinrui Machinery Co., Ltd. is a professional manufacturer of PE mills and PVC crusher equipment. We have an excellent R&D team and technicians, which lays the foundation for producing high-quality machines.
Established in 2007, Songhu Xinrui has been committed to providing the world with the best quality plastic PE grinding and PVC crushing machinery. With a top-notch team and the strictest manufacturing standards, Songhu Xinrui has become a leader in domestic plastic machinery manufacturing. Our products include PE grinding machines, PVC crushing machines, and other plastic recycling machinery, suitable for sheets, small pipes, plastic steel, resin tiles, wall panels, buckle plates, pipes, foam boards, footings, and many other materials. Songhu Xinrui's products have been exported to more than 50 countries and regions worldwide.
We offer a range of products to meet various needs. Since our company's establishment, we have adhered to the business policy of "Quality First, Customer First, Reputation-Based," and we believe that "the most suitable is the best." We are confident that quality products and reliable service can elevate your business to the next level. We are committed to continuous innovation and discovery to meet the diverse needs of our customers. In today's globalized economy, our company is eager to cooperate with enterprises worldwide to achieve mutual benefits and win-win situations.
FAQ
Q: Are you a machinery factory or a trading company?
A: We have our factory, which allows us to strictly guarantee product quality and lead times.
Q: If we have a very special request for the production line, can you help with the design?
A: Yes, our experienced mechanical designers can provide customized designs.
Q: Do you provide material testing services?
A: Yes, we offer testing services for our machines. An additional testing fee will apply, depending on the costs (electricity, labor). However, if you purchase with us, the testing fee will be deducted from the machine's purchase cost.
Q: How can I ensure the machine runs well in my plant?
A: We conduct a home commissioning in our factory for your inspection. If needed, we can send engineers for installation assistance and staff training, and to address any issues.
Q: How can I get a quote efficiently?
A: Click the 'Send an Inquiry' button at the bottom of the page or 'Chat Now' on the right side. Leave a message with details of your final products (including pictures and size drawings) and capacity requirements. We will respond within 12 hours.
Q: How can we visit your company and machines?
A: Our factory is located in Wuxi, Jiangsu Province, China.
Q: What are the payment methods?
A: We accept T/T, L/C, Western Union, etc.

---
