25 kvar Power Bank Capacitor

Product Description

Brand Name:
Huizhong
Model Number:
H55334 Three Phase
Application:
Power
Capacitance:
5Kvar-30Kvar
Rated Voltage:230Vac-525Vac
Operating Temperature:-40/+55
Power Capacitor:
Packaging & Delivery
Packaging Details:Exporting Standard Packing.
Can offer bulk packing,Foam packing,then use pallet.
TBD by clients.
Delivery Time:15 days
Power Faction Correction
The self-healing PFC capacitor for low voltage application produced by Huizhong are using the PP film with special metallization of Zn/AL and self-made filling material for the impregnation.The capacitors are manufactured in accor-dance with standard of GB/T12747-2004 and IEC60831-1+/2,which are mainlyapplied in Low voltage foe increasing the power quality.The product performance has been inproved a lot these years with low loss,low heat dissipation,no leakage,long life and consistency in quality.through our research and experiment.

Power Capacitor Power Faction Correction

Power Capacitor (Polyproplene film capacitor)
Standard IEC60831-1/2,UL810
Product series	H55334 Three Phase	H55324 Three Phase	H55100 Single Phase
Features
Output Kvar	5Kvar-30Kvar	0.5Kvar-5Kvar	0.7Kvar-5Kvar
Rated frequecy	50/60Hz	50/60Hz	50/60Hz
Rated voltage	230Vac-525Vac	230Vac-525Vac	230Vac-525Vac
Capacitor tolerance	-5%/+10% other on request	-5%/+10% other on request	-5%/+10% other on request
Electrical test VTT	2.15 x VR during 2s	2.15 x VR during 2s	2.15 x VR during 2s
Insulation VTC	3000VAC/50Hz during 10s	3000VAC/50Hz during 10s	3000VAC/50Hz during 10s
*tan 6 (50Hz)	≤1.0x10-3	≤1.0x10-3	≤1.0x10-3
Protection degree	IP20	IP00(IP50 on request)	IP00(IP50 on request)
Max.permissible voltage Vmax	VR+10%(up to 8h daily)/VR + 15%( up to 30min daily)/ VR + 20%( up to 5min daily)/ VR+ 30%( up to 1min daily)
Max.permissible current Vmax	UP to 1.3·IR(A)(1.5·IR including combined effects of harmonice,over voltage and capacitance tolerance)
Surge current Is	UP to 200·IR(A)
Power dissipation*	≤0.2W/Kvar(dielectric) and ≤0.45 W/Kvar(total)
Temperature	-40/D.Max.55°C
Humidity	Av.rel.<95%
Maximum altitude	4000m
Mean life expectancy	Up to100000 hours at temperature class -40/D
Switching	Max.5000 switchings per year acc.to IEC60831
Safety
Mechanical safety	Overpressure disconnector
Max.short cicuit current	AFC:10kA according UL810 standard
Discharge resistor	≤60s to 75V or less
Power Capacitor (Polyproplene film capacitor)
Standard IEC60831-1/2,UL810
Material	Aluminium can and top	Aluminium can and top	Aluminium can and top
Dimensions	Φ:76-96mm H:163-350mm	Φ:50,63.5mm H:148mm	Φ:63.5mm H62.5,75,100,125mm
Terminals	SIGUT terminal Max.Torque:2Nm creepage distance:≥12.7mm clearance: ≥9.6mm(UI810) Max.cable cross section:25mm2 Max. Current:50A	#250 fast-on terminal 6.3x0.8 creepage distance:≥12.7mm clearance: ≥9.6mm(UI810) Max. Current:15A	#250 fast-on terminal 6.3x0.8 creepage distance:≥12.7mm clearance: ≥9.6mm(UI810) Max. Current:15A
Impregnation	Non PCB,resin filling: soft polyurethane resin
Fixing	Threaded bolt M12
Max.Torque(AI can stud)	10Nm
Approval
	Third part test approval internal test approval
Standard terminals
Discharge resistor
Standard Monting

---
