High Capacity Waste Tire Rubber Recycling Crusher Machine

Product Description

High Capacity Waste Tire Rubber Recycling Crusher Machine
Application Areas:PNGM series heavy duty type crusher is suitable for the material which has big shape, high-strength, and massive capacity. For example PE pipes, HDPE pipes, PVC pipes,water pipes,gas and fire pipelines,and so on.Description:The heavy-duty granulators of the PNGM series offer a wide array of different rotor designs with width ranging from 500 mm to 1200 mm with a diameter of 350 to 700 mm respectively. The completely welded heavy steel construction is designed to withstand the most demanding and universal applications. Rotor bearings, knife mounts, and rotor shaft are oversized. The standard V-cut creates a high quality regrind with a very low percentage of fines in the output material. The removable third stator blade is acting as a deflector wedge and allows the machine to be quickly adjusted to different application scenarios. Other standard features include easily replaceable wear plates in the cutting chamber as well as outboard bearings reducing the risk of contamination.
The wide range of rotors and hopper styles allow the PNGM series machines to be tailored to almost every application in the plastic recycling field. The PNGM series granulators/crusher are mainly used as central granulators for in house recycling applications to process thick-walled parts in one step or as a second step granulator after a shredder to reach higher throughput rates. When used to grind light materials, such as bottles the throughput can be greatly increased with the addition of a Wanrooe force feeding device. For abrasive, contaminated or highly filled materials the machines can be equipped with special wear protection, such as hard facing the rotor and housing and key parts manufactured from highly wear-resistant steels.Features of Plastic Barrel Crushing Machine:1.bearing seat outside, prevent dust coming inside, prolong service machine life
2.sectional body design, make it simple and quick to replace inner parts
3.with motor overload and power protection device, make both machine and operator safe
4.special chromium steel cutting tool structure, easy to cut all kinds of hard plastic
5 the gap of knives can be adjusted, easy for replacement
6.foot with shock absorber to reduce vibration and eliminate noise
7.optional choice for loader and cyclone
8.mainchine can customized design
9.hydraulic lid opening: check and maintain, change tools.Advantages:1.Knives are adjusted outside of the machine.
2.Specially developed deflector wedge.
3.Wide choice of rotors.
4. Well thought out housing design.
5.Strong Welded Steel construction- Oversized outboard bearings.
Technical Parameters:

Model	Blades (PCS)		Ginder Chamber Dimensions (mm)	Power (kw)	Mesh (mm)
	Fixed	Rotating
PNGM-35/60	2*2	3*2	600*360	22-30	Φ12-Φ50
PNGM-42/08	2*2	3*2	800*420	30-45	Φ12-Φ50
PNGM-42/10	2*2	3*2	1000*420	37-55	Φ12-Φ100
PNGM-63/10	2*2	5*2	1000*630	55-110	Φ12-Φ100
PNGM-63/12	2*2	5*2	1200*630	75-132	Φ12-Φ100
PNGM-70/10	2*2	7*2	1000*700	75-132	Φ12-Φ100
PNGM-70/12	2*2	7*2	1000*700	90-160	Φ14-Φ100

Our Service 1. One year guarantee for whole machine.
2. 24 hours technical support.
3. Our engineers can provide service overseas. The service is free, but the charge of round air-tickets, food and hotel is to the customer's account.
4. After a year, we can instruct you how to maintain the machine, and spare parts are provided with the best price.
5. We also can provide training service which help operators handle the machine well.

---
