Three Axies 250CNC Smart Surface Grinding Polishing Machine for Professionals

Product Description

250/2550CNC Surface Grinding MachineThe Three Axies 250CNC Multifunction Grinding Machine Tool is a marvel of engineering designed to enhance productivity and precision.
Our commitment to excellence is unwavering. We continuously improve our products and reserve the right to innovate and modify specifications, mechanics, or designs as needed, without prior notice or obligation.

	parameter	unit	CNC-250	CNC-2550
general picture	Table size (x*y)	mm	200×500	250*500
	X axis travel	mm	580	580
	Y axis travel	mm	230	280
	Max center of wheel to table	mm	380	380
	Maximum load	kg	200	200
Table	Table T cell specification	mm×N	14×1	14×1
	Table speed	m/min	0-25	0-25
Y axis	Minimum feed	mm	0.001	0.001
	Single feed		0.1~10	0.1~10
	Fast moving speed	mm/min	0~1200	0~1200
Z axis	Minimum feed	mm	0.001/0.01	0.001/0.01
	Fast moving speed	mm/min	0~800	0~800
grinding	grinding wheel size max	mm	Φ200×Φ31.75×19
	grinding wheel speed	R.P.M	0~3600	0~3600
motor	spindle motor	HXP	2×2	2×2
	the Z axis motor	W	750	750
	the Y axis motor	W	750	750
	the X axis motor	W	1500	1500
	cooling motor	W	90	90
Size	height of machine	mm	2000	2000
	floor space	mm	2000×1350	2000×1450
	weight(about)	kg	1450	1550

Cheng Yu Machinery Technology Co., Ltd., based in Dongguan City, Guangdong Province, draws upon 30 years of Taiwanese expertise in grinding machine manufacturing, with a wealth of technological experience among our skilled team. In the thriving world of CNC machine tools, the evolution towards high-speed, high-precision, and intelligent solutions is paramount. Embracing a future of open architecture, parallel drive systems, networking capabilities, and eco-friendly practices is our mission. Dongguan Chengyu Machinery Technology Co., Ltd. stands at the forefront of machine tool production and processing. Guided by our ethos of 'technology, innovation, reliability,' and a meticulous quality policy, we are dedicated to delivering exceptional products and customer service. Our comprehensive approach considers customer processes, technology, production types, and quality requirements to craft and enhance products that expand the realm of numerical control. Our focus is on achieving high automation, precision, and quality, supported by a robust quality management system, superior equipment, and unparalleled expertise. Chengyu Machinery is attuned to market demands, specializing in creating high-precision CNC surface grinding machines, CNC forming machines, four-axis punch grinders, vertical slider grinders, and gantry rail grinders. We also design industrial robots and automated production lines for integrated applications. Here’s a glimpse into our esteemed CNC grinding machine series: I. HS Series 618 / 250 / 3060 / 4080 / 40100 (Available in servo and hydraulic types) Processing Capabilities: Masterful in surface grinding and grooving. Our hydraulic type boasts a patented hydraulic control system for precision operations. Functionality: Equipped with diverse grinding programs including flat surface and groove cutting. Flexible Feed Modes: Choose from front, back, left, or right. Each grinding program remembers your selected feed mode. Innovative Safety: Grinding wheel overload triggers an automatic shutdown to protect the equipment. II. Available in both servo and hydraulic types, tailored for versatility. Processing Excellence: Surface grinding, grooving, and combined scheduling capabilities. Experience the patented hydraulic control system for enhanced precision (hydraulic type). Comprehensive Functions: Offers a variety of grinding programs such as surface grinding, groove cutting, sole grinding, side grinding, and advanced displacement grinding. Precision Dressing: Automated wheel dressing for rough or fine grinding ensures optimal performance, with automatic compensation. Adaptive Feed Options: Front, back, left, and right options allow tailored grinding program memory feed modes. Advanced Grooving: Provides equidistant and non-equidistant unequal grooving solutions. 3. Four-axis CNC grinding machines are versatile, available in both horizontal and vertical configurations. Processing Types: Mastery in arbitrary equal division and skipping tooth processing. Precision Geometry: Configure waist circle dimensions by entering AB size. Triangle Fillet Expertise: Input inscribed circle size B and fillet size R for precision operations. Quadrilateral Fillet Precision: Define side lengths A and B, along with fillet size R, for exacting output. Eccentric Circle Crafting: Enter eccentricity, along with starting and ending diameters, for custom solutions. Circle: Please input the starting and ending diameters to effortlessly craft the perfect circular shape with our sophisticated machinery. Arc: Simply enter the desired arc size and rotation angle to achieve precise and elegant arcs, tailored to your specifications. Step Difference and Rotation Profile: Customize intricate details such as step differences and rotation profiles with ease, ensuring flawless results every time. Processing Schedule: Save your processing schedule as a file, allowing for quick and seamless recall, streamlining future operations and enhancing efficiency.

---
