Our factory is professional ATV manufactory ,We are capable of producing over 50,000 sets annually .We have professional sales team with rich export experience to USA, Korea, Italy, Dubai, Spanish, South Africa, India ect. Over 11 years of production department, technical department and lntimate after-sale service for ATV.We have more than 50models for your selection with very competivive price.
| 1. engine type :50cc/70cc/90cc/110cc,4 storke |
| 2. max torque :4.2Nm/5000rpm , 4.2Nm/5000rpm, 5.2Nm/5000rpm, 5.5Nm/5000rpm |
| 3. max power :3.0Kw/8500rpm/ ,3.0kw/7500rpm,3.3kw/7500rpm,3.6kw/7500rpm, |
| 4. ignition type :CDI |
| 5. transmission :automatic |
| 6.Brake (Front/Rear):Drum/Disc |
| 7. starting system :Electric start |
| 8. battery spec :12V,4AH |
| 9. rear suspension details :mono shock swing arm |
| 10. front tire spec : 145/70-6 |
| 11. rear tires spec : 145/70-6 |
| 12. vehicle dimensions :114x74x64cm |
| 13. wheel base :690mm |
| 14. seat height from ground :60cm |
| 15. ground clearance :100mm |
| 16. load capacity :40kg |
| 17. fuel tank capacity :3.4L |
| 18. gross weight in carton :76kg |
| 19. net weight :69kg |
| 20. packing size:114x65x64cm |
| 1. engine type :196cc/248cc,4 storke |
| 2. max torque : 13.5Nm/5500rpm, 17.5Nm/5000rpm |
| 3. max power :10kw/7500rpm,11kw/7500rpm |
| 4. ignition type :CDI |
| 5. transmission :manual clutch,4-speed,reverse gear,chain/shaft,drive |
| 6.Brake (Front/Rear):Drum/Drum for shaft),Disc(for chain) |
| 7. starting system :Electric start |
| 8. battery spec :12V,9AH |
| 9. front suspension details :double A x swing arm |
| 10. rear suspension details :mono shock swing arm |
| 11. front tire spec : 23 x 7-10 rear tires spec : 22 x 10-10 |
|
| 12. vehicle dimensions :208x124x113cm |
| 13. wheel base :1160mm |
| 14. seat height from ground :90cm |
| 15. ground clearance :155mm |
| 16. load capacity :165kg |
| 17 fuel tank capacity :11L |
| 18. gross weight in carton :240kg |
| 19. net weight :220kg |
| 20. packing size:194x109x86cm |
| 1. engine type :300cc Water Cooled,CVT |
|
| 2. max torque : 19.5Nm/5000r/min,20.5Nm/5000r/min |
| 3. max power :13Kw/6500r/pm |
| 4. ignition type :CDI |
| 5. transmission :Automatic |
| 6.Brake (Front/Rear):Disc/Disc |
| 7. starting system :Electric&pull start |
| 8. battery spec :12V,9AH |
| 9. vehicle dimensions :2500x1270x1100mm |
| 10. front tire spec : 130/60-13 rear tires spec : 270/30-14 |
| 11. fuel tank capacity :12L |
| 12. gross weight in carton :250kg |
| 13. net weight :240kg |
| 14. packing size:2320x1280x1050mm |
| 15.wheelbase 200cm / seat height 70cm /ground clearance 8.5cm |
