Product introduction of waste oil distillation equipment
waste oil distillation equipment can process waste engine oil, used motor oil, black oil, tire oil, plastic oil to clean diesel. This kind of diesel can be used to tractors, trucks, diesel oil generator, power generator etc. Oil recovery average rate: 85%-95%. Unique design and outstanding functions can help customer create more profit. This equipment is matched with pyrolysis plant. It is widely applied in waste oil management industry.
Technical parameter of waste oil distillation equipment
|
|
Items
| Contents
|
Model
| DY-5T, DY-10T, DY-15T, DY- 20T...
|
Raw material
| used motor oil, waste engine oil, tire pyrolysis oil, plastic pyrolysis oil
|
Structure form
| Vertical (easy cleaning and maintenance)
|
Heating method
| Indirect heating to prolong the machine service life
|
Operating pressure
| Constant pressure
|
Heating material
| Coal, charcoal, fuel gas, fuel oil
|
Average out-put oil rate
| 95%
|
Material of reactor
| 4 reactor with different material
|
Thickness of reactor
| 18mm
|
Mode of cooling
| Recycled water cooling
|
Power in total
| 20 Kw
|
Service life
| average 7 years
|
Land area
| 180 square meters
|
The working process of waste oil distillation equipment
1. Heat the heat conduction oil with the heat conduction oil furnace;
2. The heat conducting oil flows into the coil in the distillation reactor and heats the waste engine oil in the distillation reactor;
3. When the waste engine oil is heated to a certain temperature, the reactor is directly heated with fuel. As the temperature increases, the waste engine oil produces oil and flows into the buffer tank. The odorous light components in the waste engine oil can be distilled and collected into the distillation tank.
4. The oil gas from the buffer tank enters the catalytic tower. In the catalytic tower the macromolecular oil gas are broken down into smaller molecules .
5. Oil gas of small molecules enter the cooling system through the catalytic tower and are cooled into liquid oil;
6. After the oil gas steam out, the distillation reactor memory has plenty of hot asphalt, which can be extracted by the asphalt pump.
The products of waste oil distillation equipment
Two products can be obtained from the waste oil distillation equipment, 80%-85% diesel, 15%-25% asphalt. For the 80-85% diesel oil, you can used it into heavy machinery, gernerator, and boiler. For the 15%-25% asphalt, could be used for paving, or directly sold to asphalt refineries for further refining.
The unique advantages of DOING waste oil distillation equipment
Safety:
Safety is the most important factor in the whole process. We had successfully researched some safety devices which ensure waste oil distillation equipment work safely.
1. Safety valves, alarming device and the pressure gauge etc.
2. We also have oil-water separator which can stop the oil gas recycle to the reactor, which could avoid the accident.
3. High degree of automation: feed the waste oil, crude oil automatically, to pump oil automatically.
Energy saving:
1. Well sealing for heating system, no gas leak and saving fuel.
2. Continuous feeding with automatic feeder, no gas leak.
3. Recycling of exhaust gas and scientific fire channel design can save energy and thereby reducing costs.
Environmental friendly:
1. The whole process is all sealed, won't release any gas harmful to human and environment.
2. Well water dedusting system can avoid black smoke.
Packaging & Shipping
The packaging &shipping of waste oil distillation equipment
Project case of waste oil distillation equipment
With mature production technology and professional sales, engineers and installation team, through the unremitting technological innovation and following the market demand, we have installed machines in more than 60 countries around the world, including:
Asia: China, Bangladesh, Malaysia, Pakistan, India, Thailand, Philippines
Mid-east: Lebanon, Jordan, Palestine, United Arab Emirates, Saudi Arabia, Iran
Africa: South Africa, Egypt, Nigeria, Kenya, Congo, Uganda, Serbia, Senegal, Cameroon, Kenya, Liberia, Algeria, Ethiopia
Americas: Columbia, Panama, Mexico, Jamaica, Chile, Guatemala, Ecuador, Aruba, Haiti, Argentina, Canada
Europe: Romania, Italy, Czech Republic, Estonia, Macedonia, Poland, Turkey, France, Albania, Georgia
Oceania: Australia, etc
Our Services
After-sales service of waste oil distillation equipment
1. Delivery time
It will be 10-15 days after we receive the deposit.
2. Warranty
The warranty period for reactor and other parts except spare parts is 1 year. The problem caused by wrong operation of workers shall not be responsible by our company.
3. Installation and Training
Our company will send one technician for each set of machine for guiding your installation, testing the machine and training your worker.
We have a professional customer service process to ensure customers' satisfaction from contact us to machine installation and after-sale service. If you have any question about the waste oil distillation equipment, please contact us in time and you will get a satisfactory solution!
Company Information
Henan Doing Machinery Equipment Co., Ltd. has been dedicated to the research and development of large and medium-sized renewable energy environmental protection equipment and a variety of waste recycling equipment for years. We are professional manufacturing enterprise which gather development, design, production, sales, installation and after-sales service in one. DOING's business scope involves waste tire/plastic/rubber pyrolysis equipment, waste oil to diesel fuel refinery.
DOING's office headquarters is in Zhengdong New District of Zhengzhou City, and DOING's manufacturing factories are located in Xinxiang and Jiaozuo city, the factory covers an area of over 40,000 square meters.
FAQ
FAQ of waste oil distillation equipment
Q: Are there any bad smell or odor from DOING waste oil distillation equipment while distillation system is working?
A: There will be no smell at all as the gas produced by DOING waste oil distillation equipment will be purified by our exclusive tail gas purification unit before emission.
Q: What is the yield of this waste oil distillation equipment?
A: Typically the yield of our waste oil distillation equipment is between 85-90% (depending on variations of water content, light HC and others ingredients from waste oil.)
Q: How many areas are required to build the waste oil distillation equipment?
A: The land area required usually depends on the capacity of your plant. We can calculate the area needed and give you the plant designs.
Q: What is the warranty of the waste oil distillation equipment?
A: 12 months free guanantee and life long standard paid service.
Q: Can you install the production line and train our stuffs?
A: Yes we can. We'll send engineers to help you install the waste oil distillation equipment and train your workers until the machine is skillfully operated.
Q: What is the operation cost of this waste oil distillation equipment?
A: Please consult one of our sales representative for more information about operation cost and turnover of capacity you are interested. We will be providing you the professional budgets breakdown for your particular project.
Q: How to ask quotation?
A: Please inform us your crude oil specifications and your target capacity per day, then we will send our proposal as soon as possible. Also you can contact us by the following ways:
Phone: +86-371-5677 1821
Mobile/Wechat/Whatsapp:0086-135-2669- 2320
Skype: bonniezhao2
