| Name | Silicone Thread Mask Plug |
| Material | Silicone, EPDM |
| Hardness | 50 Shore A, ± 5 Shore A |
| Temperature | -20°C to +250°C |
| Size | According to the drawing or sample |
| Color | According to your requirement (Panton color card) |
| Application | Automotive, industrial, machinery, electrical, medical, household etc |
| Performance | Good sealing & damping; Waterproof; Aging/ozone/oil/pressure resistance; Low & high temperature resistance |
| Mode of Production | Compression, transfer |
| Production Capabilities | Machines including 150T,200T,250T, 300T |
| Testing instruments | Vulcanization tester, tensile tester, rubber durometer, insulation resistance tester etc |
| Rubber Compound | Can be FDA, RoHs or REACH approved, and free test slabs and hardness testers can be offered for customer's testing |
| Package | Inner plastic bag/outside carton/wooden pallets/ or any other special package as per customer's requirements |
| Notes | Models and logos can be customized as your requirements; Designs and specifications are accepted |
| Number | PART NO. | A | B | C | Total Height | |||
| in | mm | in | mm | in | mm | in | ||
| 1 | TMP-0107 | 0.107 | 2.72 | 0.210 | 5.33 | 0.138 | 3.51 | 0.820 |
| 2 | TMP-0141 | 0.141 | 3.58 | 0.230 | 5.84 | 0.161 | 4.09 | 0.860 |
| 3 | TMP-0178 | 0.178 | 4.52 | 0.220 | 5.59 | 0.207 | 5.26 | 0.820 |
| 4 | TMP-0208 | 0.208 | 5.28 | 0.295 | 7.49 | 0.248 | 6.30 | 0.964 |
| 5 | TMP-0210 | 0.210 | 5.33 | 0.200 | 5.08 | 0.25 | 6.35 | 0.570 |
| 6 | TMP-0218 | 0.218 | 5.54 | 0.200 | 5.08 | 0.26 | 6.60 | 0.450 |
| 7 | TMP-0218L | 0.218 | 5.54 | 0.279 | 7.09 | 0.26 | 6.60 | 0.922 |
| 8 | TMP-0278 | 0.278 | 7.06 | 0.200 | 5.08 | 0.32 | 8.13 | 0.500 |
| 9 | TMP-0278L | 0.278 | 7.06 | 0.279 | 7.09 | 0.32 | 8.13 | 0.894 |
| 10 | TMP-0283 | 0.283 | 7.19 | 0.200 | 5.08 | 0.335 | 8.51 | 0.586 |
| 11 | TMP-0283L | 0.283 | 7.19 | 0.295 | 7.49 | 0.331 | 8.41 | 0.896 |
| 12 | TMP-0336 | 0.336 | 8.53 | 0.250 | 6.35 | 0.385 | 9.78 | 0.600 |
| 13 | TMP-0336L | 0.336 | 8.53 | 0.329 | 8.36 | 0.385 | 9.78 | 0.994 |
| 14 | TMP-0358 | 0.358 | 9.09 | 0.241 | 6.12 | 0.409 | 10.39 | 0.615 |
| 15 | TMP-0358L | 0.358 | 9.09 | 0.276 | 7.01 | 0.409 | 10.39 | 0.945 |
| 16 | TMP-0394 | 0.394 | 10.01 | 0.350 | 8.90 | 0.45 | 11.43 | 0.750 |
| 17 | TMP-0426 | 0.426 | 10.82 | 0.346 | 8.79 | 0.489 | 12.42 | 0.789 |
| 18 | TMP-0451 | 0.451 | 11.46 | 0.352 | 8.94 | 0.51 | 12.95 | 0.750 |
| 19 | TMP-0477 | 0.477 | 12.12 | 0.300 | 7.62 | 0.5497 | 13.96 | 0.866 |
| 20 | TMP-0510 | 0.510 | 12.95 | 0.300 | 7.62 | 0.55 | 13.97 | 0.875 |
| 21 | TMP-0583 | 0.583 | 14.81 | 0.408 | 10.36 | 0.67 | 17.02 | 0.906 |
| 22 | TMP-0643 | 0.643 | 16.33 | 0.375 | 9.53 | 0.733 | 18.62 | 1.282 |
| 23 | TMP-0724 | 0.724 | 18.39 | 0.512 | 13.00 | 0.811 | 20.60 | 1.127 |
| 24 | TMP-0825 | 0.825 | 20.96 | 0.375 | 9.53 | 0.915 | 23.24 | 1.282 |
| 25 | TMP-0840 | 0.840 | 21.34 | 0.535 | 13.59 | 0.941 | 23.90 | 1.302 |
| 26 | TMP-0896 | 0.896 | 22.76 | 0.630 | 16.00 | 0.947 | 24.05 | 1.490 |
| Our Service | ||||||||||
| 1. Thousands of lines in multiple sizes | ||||||||||
| 2. Free samples | ||||||||||
| 3. Sufficient stock | ||||||||||
| FAQ | ||||||||||
| Q1. Can you provide sample to test? | ||||||||||
| Yes, Hengnai China provides customers free samples and catalog within one day on request. | ||||||||||
| Q2. What's your MOQ? | ||||||||||
| Hengnai China have no MOQ requirement, we offer Mini pack and Micro Pack to meet your less than case quantity requirement. | ||||||||||
| Q3. What's your delivery time? | ||||||||||
| 3 working days for thousands of in-stock items; | ||||||||||
| 1-2 weeks for non-stock itmes. | ||||||||||
| Q4. What's your incoterms? | ||||||||||
| EXW,FOB,CIF,CFR. | ||||||||||
| Q5. What's your terms of payment? | ||||||||||
| T/T 100% in advance. | ||||||||||
| Q7: Can you make the plastic or rubber parts in different colors and shapes? | ||||||||||
| Yes, Hengnai is glad to provide the parts in different colors to meet the customer's requirement. For custom parts, please contact the sales to get more detailed reply. | ||||||||||
