4 Post Car Lift with Wheel Alignment Function (ORL-435A)

Product Description

4 post lift with wheel alignment function
FEATURES:
*Suitalbe used in the car 4S shop and the repair and maintain service workshop as vehicles lifting,may also cooperating used with wheel alignment.
*4000kg/5000kg lifting capacity.
*Air release,easy to be operated,and provide electric release for choose.
*Aluminum shell motor prevents overheated.
*Low profile,minimum height is 200mm.
*Hydraulic cylinder located inside of runway, perfectly protected.
*The heavy duty steel wire drum, ensures the vehicles safety.
*Adjustable runways make lift suitable for more versatile vehicles.
*The automatic operated mechanical lock engaged in process to ensure the vehicles lifting safety.
*Runway synchronizer system provided for preventing vehicles from tilt possibly.
*The hydraulic system is equipped with device for over-load prevention.
Accessories
Overall Dimensions:
Technical Data

Liftting Capacity	3500kg
Lifting Height	1800mm
Min. Height	220mm
Overall Height	2120mm
Jack Capacity	2500kg
Runway Length	4250mm
Runway Width	508mm
Lifting Time	60s
Rated Oil Pressure	18Mpa
Motor Power	2.2kw
Power Supply	220V/240V/380V/415V
Weight	1384kg
Packing Size	4570/5100*560*730+820*340*360mm

---
