Silent Type Prime Power 400kw 500kVA Cummins Kta19-G4 Power Diesel Generator Price

Product Description

Product Description GENLITEC POWER Silent Type Prime Power 400kw 500kVA Cummins Power Diesel Generator Price
Δ STANDARD CONFIGURATION
1) Powered by brand new original CUMMINS water cooled diesel engine.
2) Brand new single bearing 3 phase alternator with IP23 and H insulation class.
3) Original CUMMINS 50ºC radiator with engine driven fan mounted on skid.
4) Delixi or Chint branded case circuit breaker mounted.
5) Heavy-duty fabricated steel based frame with built-in fuel tank for at least 8 hours continuous running.
6) Complete set mounted on a based frame with anti-vibration mountings.
7) Industrial 9 dB muffler exhaust system with blexible connects and bellows.
8) Based frame with fuel, oil and coolant drain cocks for easy maintenance.
9) 12/24V DC electric start system with free maintain battery & smartgen brand battery charger.
10) Set mounted automatic control panel, with SMARTGEN brand AMF controller module for automatic start & stop.
11) Test report of generator, set of drawings and manuals.
12) CE, ISO9001 approved
Δ TESTING ITEMS
GENLITEC POWER provides a full line of brand new and high quality products.
Each and every unit is strictly factory tested before shipment.
1) Parts faults testing
2) Fuel tank pressure testing
3) Bolt tightening torque testing
4) Painting thickness testing
5) Voltage bearing and insulation testing
6) Noise testing
7) Loading Testing: 25%, 50%, 75%, 100%, 110% load to check verify that all control systems, alarm and shut-down protection.
Δ OPTIONAL SUPPLY
1) Weatherproof canopy / Soundproof canopy / Trailer-mounted
2) Engine / Alternator Pre-heaters
3) Auto load sharing & synchronization panel
4) Build-in ATS (Auto start & stop Main Failure (AMF)
5) Large 12/24 hours fuel tank
6) Power output sockets
Technical Specifications

MODEL	GPC500S5-III
Prime Power (50HZ)	400KW/500KVA
Standby Power (50HZ)	440kw/550KVA
Power Factor	0.8 (Lagging)
Phase Wires	3-phases 4-Wires
Start Model	DC 24V Electric
Protection	Low oil-pressure, High water temperature,
	Over-speed, Over-current
Engine Model	CUMMINS KTA19-G4 4-Cycle
Cylinders	6
Cylinder Arrangement	L
Bore x Stroke(mm)	159X 159
Compression Ratio	13.9:1
Speed	1500rpm
Cooling Method	Water - cooled
Starting Method	24V DC electrical start
Full Load Diesel Consumption (L/H)	97
Engine Displacement (L)	19
Inspiration (L)	Turbocharged Intercooled
Lube Volume (L)	50
Coolant Volume (L)	95
Noise (Db)	≤ 80
Alternator Model	HCI544C
Alternator Power	400KW/500KVA Brushles with AVR
Voltage	380/220V,400/230V,415/240V,220/127V
Protection	IP23
Voltage Regulation	±1%
Insulation Class	H
Voltage Control	AVR
Controller	DEEPSEA DSE7320
Optional	ATS (auto transfer switch)
	AMF(auto mains failure)
	Containerized

Detailed Photos
Product Parameters

Genset Model		Prime Power		Standby Power		Fuel Consumption	Engine Model	Cylinder Arrangement	Displacement
Open	Silent	KW	KVA	KW	KVA	L/H (75%)			(L)
GPC375D5-I	GPC375S5-I	300	375	330	413	56	6ZTAA13-G3	6L	13
GPC375D5-II	GPC375S5-II	300	375	330	413	64.7	NTAA855-G7	6L	14
GPC400D5	GPC400S5	320	400	352	440	65	6ZTAA13-G2	6L	13
GPC450D5-I	GPC450S5-I	360	450	400	500	67	6ZTAA13-G4	6L	13
GPC450D5-II	GPC450S5-II	360	450	400	500	73	KTA19-G3	6L	19
GPC500D5-I	GPC500S5-I	400	500	440	550	74	QSZ13-G3	6L	13
GPC500D5-II	GPC500S5-II	400	500	440	550	82	KTA19-G3A	6L	19
GPC500D5-III	GPC500S5-III	400	500	440	550	82	KTA19-G4	6L	19
GPC525D5	GPC525S5	420	525	460	575	91	KTAA19-G5	6L	19
GPC575D5	GPC575S5	460	575	520	650	88.2	KTAA19-G6	6L	19
GPC650D5-SP	GPC650S5-SP	/	/	520	650	94	KTA19-G8	6L	19
GPC690D5-SP	GPD690S5-SP	/	/	550	690	95	KTAA19-G6A	6L	19
GPC650D5	GPC650S5	520	650	570	712	111	QSK19-G4	6L	19
GPC725D5	GPC725S5	580	725	640	800	115	KT38-GA	12V	38
GPC750D5	GPC750S5	600	750	660	825	128	KTA38-G2	12V	38
GPC800D5	GPC800S5	640	800	704	880	135	KTA38-G2B	12V	38
GPC910D5	GPC910S5	728	910	800	1000	147	KTA38-G2A	12V	38
GPC1000D5	GPC1000S5	800	1000	880	1100	161	KTA38-G5	12V	38
GPC1125D5	GPC1125S5	900	1125	1000	1250	178	KTA38-G9	12V	38
GPC1250D5	GPC1250S5	1000	1250	1100	1375	195	KTA50-G3	16V	50
GPC1375D5	GPC1375S5	1100	1375	1210	1512	238	KTA50-G8	16V	50
GPC1500D5	GPC1500S5	1200	1500	1320	1650	238	KTA50-GS8	16V	50
