CNC Machine CNC Milling Machine with Double Head to 650mm

US$48,000.00-52,500.00 1 Piece (MOQ)

Basic Info.

Model NO.

TM-650NC

Application

Metal

Process Usage

Metal-Cutting CNC Machine Tools, CNC Non-Conventional Machine Tools, Metal-Forming CNC Machine Tools

Movement Method

Linear Control

Control Method

Closed-Loop Control

Numerical Control

CNC/MNC

Processing Precision

0.01~0.02(mm)

Performance Classification

Economical CNC Machine Tools

Certification

GS, CE, RoHS, ISO 9001

Condition

New

Model

TM-650nc

Machine Capacity

30*30-650*650mm

Max Process Thickness

240mm

X,Y-Axis Displacement

10m

Z-Axis Displacement

10m

X,Y-Axis Travel

500mm

Z-Axis Travel

1050mm

Spindle(Taper)

BT50

Spindle Speed

50-600 Rpm/Min

Tool Disc Diameter

250mm

Spindle Servo Motor

11kw

Z-Axis Servo Motor

3 Kw

X,Y-Axis Servo Motor

2 Kw

Dividing Disk Diameter

380mm

Mechanical Weight

8000kg

Transport Package

Standard Exporting Package

Specification

L4800xW3800xH2800mm

Trademark

TEMY

Origin

China

HS Code

8459210000

Production Capacity

500 Sets/ Year

Product Description

CNC Double Head Milling Machine
Model: TM-650NC
The double-head milling machine is a kind of machining equipment mainly used in the manufacturing industry. It is equipped with two milling heads, which can work simultaneously or independently according to the processing requirements. These milling heads are usually driven by high-power motors to provide sufficient torque and rotational speed for milling operations.
The double-head milling machine has high processing efficiency and precision. It can complete the milling of complex workpieces in one operation, reducing the processing time and improving the production efficiency. It is widely used in the processing of various materials such as metal, wood and plastic, and is suitable for manufacturing parts with high precision requirements, such as mechanical parts, mold manufacturing and so on.
