| US$100,000.00-200,000.00 | 1 Piece (MOQ) |
| Item | Value | Remarks | |
| Working performance | Max. rated lifting capacity kg | 110000 | |
| Max. load moment of basic boom kN.m | 3540 | ||
| Max. load moment of max. length main boom kN.m | 1728 | ||
| Max. lifting height of basic boom m | 13.7 | ||
| Max. lifting height of main boom m | 59.2 | These parameters do not include deflection of main boom and jib. | |
| Max. lifting height of jib m | 86.0 | ||
| Working speeds | Max. hoist rope speed (Main winch) m/min | ≤130 | Drum 4th layer |
| Max. hoist rope speed (Auxiliary winch) m/min | ≤110 | Drum 2nd layer | |
| Boom derricking up time s | 60 | ||
| Boom telescoping out time s | 480 | ||
| Slewing speed r/min | 0 - 1.6 | ||
| Max. driving speed km/h | 90 | ||
| Max. gradeability % | 40 | ||
| Min. turning diameter m | 23 | ||
| Min. ground clearance mm | 310 | ||
| Oil consumption per hundred kilometer L | 46 | ||
| Mass | Deadweight in driving condition kg | 50000 | |
| Complete vehicle kerb mass kg | 49805 | ||
| Front axle load kg | 24000 | ||
| Rear axle load kg | 26000 | ||
| Dimensions | Overall dimensions (L × W × H) mm | 15000×2850×3820 | |
| Outrigger spread (L) m | 6.38 | ||
| Outrigger spread (W) m | Fully extended: 8.0 m Intermediately extended: 5.3 m | ||
| Tail slewing radius mm | 4420 | ||
| Main boom length m | 12.5-58.5 | ||
| Boom angle ° | -2 - 80 | ||
| Jib length m | 10.4, 17.5 | ||
| Jib offset ° | 0, 15, 30 | ||
| Extension length m | 9.5 | Optional | |
| Extension offset ° | 0 | ||
| Tip boom length m | 3 | Optional | |
| Tip boom offset ° | 30 | ||
