| Cabin | Driving type 6x2 Double Row Cab with Air condition | ||
| Vehicle Main Dimensions | Overall dimensions (L x W x H)mm | 10000×2500×3600 | |
| Wheel base (mm) | 4325+1350 | ||
| Wheel track (front/rear) (mm) | 2022/1830/1830 | ||
| Weight in KGS | Tare Weight | 14300 | |
| Payload | 18000 | ||
| Front axles loading capacity | 1x7000 | ||
| Rear axles loading capacity | 2x13000 | ||
| Max. driving speed(km/h) | 90 | ||
| Engine | Brand | SINOTRUK | |
| Model | WD615.87 | ||
| Type | 4-stroke direct injection , 6-cylinder in-line , turbo-charged and inter-cooled | ||
| Horse Power(HP) | 290 HP | ||
| Emission standard | Euro 2 | ||
| Gearbox | HW13710, 10 Forwards gear & 2 reverse gear | ||
| Clutch | Reinforced diaphragm clutch, diameter 430mm | ||
| Steering Gear | 8098,power steering, hydraulic steering with power assistance | ||
| Fuel tank (L) | 400 liters Aluminium oil tank | ||
| Tire | 12R22.5 tubeless tyre,11 pcs including one spare tire | ||
| Tank Capacity (L) | Water: 10,000 | ||
| Foam: 2,000 | |||
| Fire Pump | Model | CB20.10/30.60 | |
| Flow | 60L/s at Low Pressure 1.0 MPa | ||
| 30L/s at Middle Pressure 2.0 Mpa | |||
| Fire Monitor | Model | PL48 | |
| Pressure | 1.0~1.2MPa | ||
| Flow | 48L/S | ||
| Range | Water≥60 m | ||
| Foam≥55 m | |||
| Rotation angle | 360° Horizontal | ||
| -30°~80° Pitch Angle | |||
