Euro5 Mini Excavators 2 Ton 3ton Xe27e Digger

Product Description

Product Description
A Compact Model with High Performance

This mini excavator is ready for today' s tough jobs. The XE27E with OPG/TOPS/ROPS (ISO 3471) canopy provides excellent visibility, stability, optimal comfort, and safety. For tough jobs in tight corners that demand precision control and state-of-the- art performance. The XE19E is ready to work, offering the following advanced features: Short-tail swing, hydraulic retractable undercarriage, boom swing, short and long arm, and powerful digging forces. Add high reliability, low operating costs, and superior efficiency, you have the ideal mini excavator for a wide range of modern jobs.
Short-tail swing
With short-tail swing, even the tightest space
becomes an efficient work place. The tail always
stays within the width of the tracks (when
extended) and lets you turn the canopy through
out its 360-degree turning radius with complete
confidence and safety. As the starting point for
developing our short-tail XE20E, balance and
fast and smooth operation were our main tar
gets. The result is a compact excavator with
excellent balance, which comes to its full poten
tial in urban environments, landscaping,
and small demolition in and outside buildings.

Retractable Undercarriage
With the standard hydraulic retractable under
carriage, passing through narrow doorways and
becomes very easy. The undercarriage
guarantees the operator better stability together
with improved lifting and loading performance.

Boom Swing
The left and right boom swing angle supports complex
operating conditions like parallel wall digging or work
ing in narrow spaces.

Engine	Make/model	D1105 /EU Stage V
	Fuel/cooling	Diesel/Liquid,forced circulation
	No. of cylinders	3
	Piston displacement	1123 cm³
	Power output	15.4 kW (20.9 hp) / 2400 rpm (ISO 14396)
	Max torque	70.3 N.m/1600 rpm
	Bore × stroke	78.0×78.4 mm
	Alternator	12 V/40 A
Swing mechanism	Boom swing, left	75°
	Boom swing, right	55°
	Slew rate	10 rpm
Drive	Travel speed (low - high)	2-3.1 km/h
	Traction force	29.7 kN
	Gradeability	30°
Weight	Operating weight with canopy and bucket	2780 kg (ISO 6016)
	Ground pressure with rubber tracks	26.4 kPa
	Transport mass (no attachment)	2650 kg
Working range	Max digging height	4390 mm
	Max dumping height	3120 mm
	Max digging depth	2800 mm
	Max digging radius	4750 mm
	Min swing radius	1980 mm
Dimensions	Overall length	4190 mm
	Overall width	1500 mm
	Overall height	2580 mm
